Introduction
Polypropylene filter is a kind of fixed aperture depth filter cartridge with the filter media of fine polypropylene fiber, the filter media comply with the FDA requirements. Filter micron rate range is from 0.1um to 60um. With the features of low pressure drop, high flow rate and long service life, polypropylene filter is the best choice as the pre filtration. The complete polypropylene structure has stable performance and wide chemical compatibility.
Specifications and Parameters
| Filter media | polypropylene filter membrane |
| Length | 10",20",30",40" |
| Diameter | 69mm |
| micron rating (µm) | 0.1, 0.2, 0.45, 0.65, 1, 2, 3, 5, 10,20,30,60 |
| end cap | doe,222/fin,222/flat,226/fin,226/flat |
| seal material | silicone,EPDM,NBR |
| sealed type | sweating soldering |
| effective filtration area | 0.4~0.7m2 /10" |
| max. working temperature | 80°C at 0.28Mpa, 60°C at 0.42Mpa |
| Max positive pressure difference | Δp0.42Mpa at 25°C |
| Max negative pressure difference | Δp0.28Mpa at 25°C |
| sterilizing temperature | 121 °C, 30min |
we still have filter media of PVDF/PTFE/PES/Nylon filter membrane~
Structure
Application
Pharmaceutical industry: medicine liquid, cell debris, biological products filtration.
Chemical industry: Organic solvents, chemical reagents, ink, plating solution filtration.
Food industry: Drinking water, mineral water, soft drinks, beer, red wine, fruit wine filtration.
Electronics industry: pre filtration of reverse osmosis water system, deionized water system.
Air filtration: compressed air,N2,CO2 filtration.
Other industry: Photoresist, magnetic media filtration.
Pictures for polypropylene cartridge
Package
10 inch: 50PCS/CTN 400*400*685mm
20 inch: 25PCS/CTN 400*400*685mm
30 inch: 25PCS/CTN 835*435*425mm
40 inch: 25PCS/CTN 1100*395*400mm
