Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.

Affordable activated carbon filter element replace for sea water 1

Affordable activated carbon filter element replace for sea water 2

Affordable activated carbon filter element replace for sea water 3

Affordable activated carbon filter element replace for sea water

Inquiry

Company Advantages
1. The combination of materials including sediment filter cartridge makes activated carbon filter element perfect in quality. Its unique density gradient construction maximizes efficiency and minimizes pressure drop
2. Good service and superior quality are key factors for success of activated carbon filter element in overseas market. It has a large effective filter area
3. The product is stable in quality and superior in performance. There is different porosity across the depth of its filter medium
4. Our professional technical team greatly optimizes the performance of our products. It can effectively control filtration precision
5. We are committed to research and development of new technology, so that our product quality and performance is in the forefront of the industry. The filter media is thermally bonded to prevent fiber release while providing consistent flow rates

Overview

Quick Details

Applicable Industries:: Food & Beverage Factory, Food & Beverage Shops

After Warranty Service:: Online support

Local Service Location:: none

Showroom Location:: none

Video outgoing-inspection:: Provided

Machinery Test Report:: Provided

Marketing Type:: Ordinary Product

Warranty of core components:: 1 Year

Core Components:: Pressure vessel

Place of Origin:: China

Brand Name:: Lvyuan/Oem

Warranty:: 1 Year

After-sales Service Provided:: Online support

Name:: 02 micron cartridge filter

Filter membrane material:: PP/PVDF/PTFE/PES/Nylon

Length:: 5 / 10 / 20 / 30 / 40 / 50 / 60 inch

Conector:: Fin/222/226/215/DOE/Thread

Micron:: 0.22/0.5/1/3/5/10/25/50/75/100/150

Sealing method:: Hot melting welding

Diameter:: 70mm/OEM

Inner Core:: PP/SS/OEM

MOQ:: Currently no limited

Supply Ability

Supply Ability:: 5000 Piece/Pieces per Week

OEM 5 10 20 30 40 inch 02 micron 5 micron 10 micron cartridge filter high flow filter cartridge

Product Description

Affordable activated carbon filter element replace for sea water 4

Product Name	Water treatment plant RO pleated filter 5 microns PP cartridge water filter with 10 20 30 40 inch length
Filtration media	PP/PTFE/PES/PVDF/Nylon
Support material	Polypropylene
Core & Structural components	Polypropylene
Inner core	PP/Stainless steel
Packing method	Polybag/Vacuum
Filtration precision	0.1μm, 0.2μm, 0.45μm, 0.65μm,0.8μm,1μm,2μm,3μm,5μm,10μm,20μm,25μm,30μm,50μm
Length	2.5", 5". 10", 20", 30", 40", 50", 60", OEM
Adaptor	215/222/226/Fin/Flat/Thread/OEM
Sealing method	Hot melting welding
Sealing gasket & O-ring material	Silicone rubber; Nitrile butadiene rubber, EPDM, Fluorine rubber.
Effect filtration area	≥0.6m²
Filter cartridge diameter	69mm
Max. working temperature	PP: 88℃,0.27Mpa； PTFE: 80℃, 0.173Mpa ；PES: 85℃, 0.28Mpa PVDF: 80℃, 0.173Mpa；Nylon: 49℃, 0.21Mpa
Max. positive differential pressure	0.42Mpa (25℃)
Max. back pressure differential pressure	0.28Mpa (25℃)
Sterilization conditions	121℃ 30min
Applications	Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;

Affordable activated carbon filter element replace for sea water 6

PP melt blown water filter cartridge

Polypropylene melt blown filter cartridge or PP spun water filter, PP filter, PP filter cartridge is the most widely used filtration consumable products in domestic and industrial water treatment systems.

PP melt blown filter cartridges (PPF) are made of 100% pure polypropylene fiber, providing broad wide chemical compatibility.
Melt Blown sediment filter cartridge has strong pollutants holding capacity.

Polypropylene microporous membrane filter

PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications. They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of
feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns. The high surface area ensures long service life and low initial pressure drops.

Affordable activated carbon filter element replace for sea water 8

Detailed Images

Affordable activated carbon filter element replace for sea water 10

Groove surface PP sediment filter cartridges.

Affordable activated carbon filter element replace for sea water 12

Flat surface PP sediment filter cartridge

Affordable activated carbon filter element replace for sea water 14

215 222 226 Flat/Fin end cap PP filter, code 0 3 6 7 8 9 available.

Affordable activated carbon filter element replace for sea water 16

DOE opened pleated filter

Affordable activated carbon filter element replace for sea water 18

OEM customized size filter

Affordable activated carbon filter element replace for sea water 20

Different end caps pleated filter

Affordable activated carbon filter element replace for sea water 22

PP melt blown filter cartridge with 1 2 3 layers for option

Affordable activated carbon filter element replace for sea water 24

PP shell Polypropylene melt blown filter cartridge

Affordable activated carbon filter element replace for sea water 26

Customize PP core or stainless steel shell/core pp filter cartridge

Affordable activated carbon filter element replace for sea water 28

Affordable activated carbon filter element replace for sea water 30

Application

Affordable activated carbon filter element replace for sea water 32

RO WATER TREATMENT

Affordable activated carbon filter element replace for sea water 34

BOTTLED MINERAL WATER

Affordable activated carbon filter element replace for sea water 36

CHEMICAL TECHNOLOGY FILTRATION

Affordable activated carbon filter element replace for sea water 38

BEER & BEVERAGE FILTRATION

Affordable activated carbon filter element replace for sea water 40

PETROCHMICAL INDUSTRY

Affordable activated carbon filter element replace for sea water 42

SEA DESALINATION WATER EQUIPMENT

Packing & Delivery

Affordable activated carbon filter element replace for sea water 44

Affordable activated carbon filter element replace for sea water 46

Affordable activated carbon filter element replace for sea water 48

Container for shipment

Affordable activated carbon filter element replace for sea water 50

Container for shipment

Certifications

Affordable activated carbon filter element replace for sea water 52

Affordable activated carbon filter element replace for sea water 54

Affordable activated carbon filter element replace for sea water 56

Our Company

Affordable activated carbon filter element replace for sea water 58

Affordable activated carbon filter element replace for sea water 60

Let's Make Custom Water Filter Cartridge For You Now.

According to the customer's order requirements, Guangzhou Lvyuan Water Purification Equipment Co., Ltd. can accurately and timely complete the production tasks with quality and quantity. Its unique density gradient construction maximizes efficiency and minimizes pressure drop. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. will strictly inspect product package to ensure water filter cartridges will be totally safe during transportation. Its unique density gradient construction maximizes efficiency and minimizes pressure drop.

Company Features
1. The engineering equipment for activated carbon filter element production in Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is in a leading position in the local area.
2. In our business sustainable development, we make plans to promote growth by investing in science and research, environmental organizations, and special group caring projects.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.

Hot Sale activated carbon filter element for Drinking Water Chlorine Removal

5 micron pp sediment filter cartridge fit in 10 inch pp water filter housing1

Stainless steel core 5 micron liquid filter 10 20 inch string wound water sediment filter cartridge for water filter housing

Water treatment wire string wound 10 20 30 40 inch cotton sediment filter cartridge with stainless steel SS core (OD2.5 inch)

10 inch pp sediment filter cartridge /melt blown water cartridge with 5 micron 10 micron
