Overview

Quick Details

Place of Origin:: China

Brand Name:: Lvyuan/OEM

Model Number:: LY-PLF-01

Power (W):: 0

Voltage (V):: 0

After-sales Service Provided:: none

Warranty:: none

Type:: Reverse Osmosis

Certification:: GS

Use:: Household Pre-Filtration

Application:: Car, RV, Outdoor, Hotel, Garage, Commercial, Household

Power Source:: Manual

Name:: filter element of water purifier

Filter membrane material:: PP/PVDF/PTFE/PES/Nylon

Length:: 5 / 10 / 20 / 30 / 40 / 50 / 60 inch

Conector:: Fin/222/226/215/DOE/Thread

Micron:: 0.22/0.5/1/3/5/10/25/50/75/100/150

Sealing method:: Hot melting welding

Diameter:: 70mm/OEM

Inner Core:: PP/SS/OEM

MOQ:: Currently no limited

Supply Ability

Supply Ability:: 5000 Piece/Pieces per Week

Custom size removal dust filter element of water purifier for condensate water

Product Description

Product Name	Water treatment plant RO pleated filter 5 microns PP cartridge water filter with 10 20 30 40 inch length
Filtration media	PP/PTFE/PES/PVDF/Nylon
Support material	Polypropylene
Core & Structural components	Polypropylene
Inner core	PP/Stainless steel
Packing method	Polybag/Vacuum
Filtration precision	0.1μm, 0.2μm, 0.45μm, 0.65μm,0.8μm,1μm,2μm,3μm,5μm,10μm,20μm,25μm,30μm,50μm
Length	2.5", 5". 10", 20", 30", 40", 50", 60", OEM
Adaptor	215/222/226/Fin/Flat/Thread/OEM
Sealing method	Hot melting welding
Sealing gasket & O-ring material	Silicone rubber; Nitrile butadiene rubber, EPDM, Fluorine rubber.
Effect filtration area	≥0.6m²
Filter cartridge diameter	69mm
Max. working temperature	PP: 88℃,0.27Mpa； PTFE: 80℃, 0.173Mpa ；PES: 85℃, 0.28Mpa PVDF: 80℃, 0.173Mpa；Nylon: 49℃, 0.21Mpa
Max. positive differential pressure	0.42Mpa (25℃)
Max. back pressure differential pressure	0.28Mpa (25℃)
Sterilization conditions	121℃ 30min
Applications	Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;

Custom size removal dust filter element of water purifier for condensate water 9

PP melt blown water filter cartridge

Polypropylene melt blown filter cartridge or PP spun water filter, PP filter, PP filter cartridge is the most widely used filtration consumable products in domestic and industrial water treatment systems.

PP melt blown filter cartridges (PPF) are made of 100% pure polypropylene fiber, providing broad wide chemical compatibility.
Melt Blown sediment filter cartridge has strong pollutants holding capacity.

Polypropylene microporous membrane filter

PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications. They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of
feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns. The high surface area ensures long service life and low initial pressure drops.

Custom size removal dust filter element of water purifier for condensate water 11

Detailed Images

Custom size removal dust filter element of water purifier for condensate water 13

Groove surface PP sediment filter cartridges.

Custom size removal dust filter element of water purifier for condensate water 15

Flat surface PP sediment filter cartridge

Custom size removal dust filter element of water purifier for condensate water 17

215 222 226 Flat/Fin end cap PP filter, code 0 3 6 7 8 9 available.

Custom size removal dust filter element of water purifier for condensate water 19

DOE opened pleated filter

Custom size removal dust filter element of water purifier for condensate water 21

OEM customized size filter

Custom size removal dust filter element of water purifier for condensate water 23

Different end caps pleated filter

Custom size removal dust filter element of water purifier for condensate water 25

PP melt blown filter cartridge with 1 2 3 layers for option

Custom size removal dust filter element of water purifier for condensate water 27

PP shell Polypropylene melt blown filter cartridge

Custom size removal dust filter element of water purifier for condensate water 29

Customize PP core or stainless steel shell/core pp filter cartridge

Custom size removal dust filter element of water purifier for condensate water 31

Application

Custom size removal dust filter element of water purifier for condensate water 33

RO WATER TREATMENT

Custom size removal dust filter element of water purifier for condensate water 35

BOTTLED MINERAL WATER

Custom size removal dust filter element of water purifier for condensate water 37

CHEMICAL TECHNOLOGY FILTRATION

Custom size removal dust filter element of water purifier for condensate water 39

BEER & BEVERAGE FILTRATION

Custom size removal dust filter element of water purifier for condensate water 41

PETROCHMICAL INDUSTRY

Custom size removal dust filter element of water purifier for condensate water 43

SEA DESALINATION WATER EQUIPMENT

Packing & Delivery

Custom size removal dust filter element of water purifier for condensate water 45

Custom size removal dust filter element of water purifier for condensate water 47

Custom size removal dust filter element of water purifier for condensate water 49

Container for shipment

Custom size removal dust filter element of water purifier for condensate water 51

Container for shipment

Certifications

Custom size removal dust filter element of water purifier for condensate water 53

Custom size removal dust filter element of water purifier for condensate water 55

Custom size removal dust filter element of water purifier for condensate water 57

Our Company

Custom size removal dust filter element of water purifier for condensate water 59

Custom size removal dust filter element of water purifier for condensate water 61

Let's Make Custom Water Filter Cartridge For You Now.

The product helps improve the flexibility of working. Because it allows operators to perform maintenance and other tasks while it is in motion. All its elements are made with FDA compliant material for food and beverage contact. The use of this product will help manufacturers hire more high-level talents, they are equipped with technical machines. This, in turn, will give manufacturers a competitive advantage. All its elements are made with FDA compliant material for food and beverage contact.
