Efficient ss316 filter housing exporter for purify

Inquiry

Overview
Quick Details
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, water treatment
Place of Origin:
Guangdong, China
Brand Name:
Lvyuan,OEM,ODM
Material:
stainless steel, SS304/SS316
Weight:
customized
Size:
customized, 30/40 inch
Power:
0
Warranty:
1 Year
After-sales Service Provided:
Online support
Feature:
easily installment
Certification:
SGS
Shape:
cylinder
Usage:
water filtration
Application:
industry
surface:
polished
Raw material:
stainless steel
Working pressure:
100Psi
Supply Ability
Supply Ability:
500 Piece/Pieces per Year
Video Description
Product Description
Efficient ss316 filter housing exporter for purify 11

General Decription


It is used to filter out fine substances (such as tiny quartz sand, activated carbon particles, etc.), bacteria and other impurities filtered by the multi-media.


According to select different use occasions, different filter precision filter elements,In order to ensure the water into RO membrane safe and the quality of outlet water.

The working principle is Mechanical filtration using different precision pores of the filter element.all contaminants can be trapped in the filter cartridges surface and in the pores because of the flow direction.

As the filtration time increases, the filter element is contaminated by impurities.The running resistance increases, and when the operating pressure difference between the inlet and outlet water reaches 0.1 MPA, the filter element should be replaced.


The main advantages of cartridge filter housing is high efficiency, low resistance and easy replacement.

Efficient ss316 filter housing exporter for purify 13
Material
SUS304, SUS316L
Cartridge length
5'', 10, 20 ,30 ,40 inch
cartridge material
pp, ptfe, pvdf, ss, etc
Cartridge core
5 to 160 core
Seal O-ring
silicone,NBR, EPDM, Viton
Surface treatment
Polishing or matte treatment
Closure
V-brand clamp/Bolt and nut
Inlet/outlet connection
1, 1.5,  2, 2.5, 3, 4'', 5, 6, 8
Usage
liquid filtration
Accept
OEM

Different stainless steel multi-cartridges filter housing are customized, as long as you offer us picture and drawing.

Efficient ss316 filter housing exporter for purify 15
Efficient ss316 filter housing exporter for purify 17
Efficient ss316 filter housing exporter for purify 19
Efficient ss316 filter housing exporter for purify 21
Application

It has been widely used in medical, chemical, electronics, beverage, fruit wine, biochemical water Treatment, environmental protection and other industries.

Efficient ss316 filter housing exporter for purify 23
Related Products
Efficient ss316 filter housing exporter for purify 25
Efficient ss316 filter housing exporter for purify 27
Efficient ss316 filter housing exporter for purify 29

                 Bag filter housing                        single cartridge filter housing                      sanitary cartridge filter housing

Efficient ss316 filter housing exporter for purify 31
Efficient ss316 filter housing exporter for purify 33
Efficient ss316 filter housing exporter for purify 35
Efficient ss316 filter housing exporter for purify 37

sintered filter cartridge    string wound filter cartridge   pp sediment filter cartridge  pleated filter cartridge

Efficient ss316 filter housing exporter for purify 39
Our Certifications
Efficient ss316 filter housing exporter for purify 41
About us

1. 10 years professional manufacturer experience.

2. We provide OEM and ODM customization service, you can find all kinds of water filter cartridge and stainless steel water filter housings in our company.

3. All products have quality warranty. Our Certification: CE ISO SGS

4. Our workers are efficient and our sales are professional, we will give the professional customized service.

5. Our products are exporting to more than 100 countries and regions. Received a good reputation.

6. Many cooperator stand by us for many years.

7. We are determined to provide the best service and good quality to our global customers, we will be more and more professional company in the future.

Efficient ss316 filter housing exporter for purify 43
Efficient ss316 filter housing exporter for purify 45
Our Service

We bulit a long-term cooperate relationship with our customers and earn a good reputation from our customer, join us and let's us get start bussiness plan.

1. Accept customized length, Package, logo etc, as you offer your drawing and picture.

2. Accept Sample purchase order .(Accept FILTER CARTRIDGE MOQ=10. water filter MOQ=1)

3. We will reply to you in 24 hours.

4. Received the payment, we will contact you at the first time and arrange the production and let you

know the lastest process.

5. Any doublt, pl contact with us, we will help you solve the problem asap.

Packing & Delivery

 Packaging:


Products are packed by high quality carton/wooden case, suitable for long distance ocean freight transportation as well as climates and with good resistance to moisture and shocks.

Delivery time:

If this kind of products is in stock, the product will be sent for you 1-7 days after payment.

If this kind of products is not in stock, the products will take about 7-25 days to produce.

Shipping:

Maritime, Railway, Air (DHL/UPS/TNT/FEDEX)
Efficient ss316 filter housing exporter for purify 47
Contact us
Efficient ss316 filter housing exporter for purify 49
From the perspective of manufacturers, it will increase the productivity of all factors of production like land, labor, capital, etc. It is designed with graded pores to help trap contaminants throughout the entire cross section for improved efficiency. The product is easily installed and comes with a complete detailed operation guide including user instructions, maintenance, and installation procedures. It is designed with graded pores to help trap contaminants throughout the entire cross section for improved efficiency.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
