High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 1
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 2
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 3
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 4
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 5
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 6
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 1
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 2
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 3
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 4
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 5
High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 6

High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns

Inquiry

    oops...!

    no product data.

    Go to homepage
    Write a Review
    Overview
    Quick Details
    Applicable Industries:
    Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
    Place of Origin:
    Guangdong, China
    Brand Name:
    Customized
    Material:
    Customized
    Weight:
    Customized
    Size:
    Customized
    Power:
    Customized
    Warranty:
    Unavailable
    Item Name:
    Stainless steel liquid cartridge filter housing
    Filter cartridge length:
    10" 20" 30" 40"
    Stainless steel:
    SUS304, SUS316L
    Cartridge filters quantity:
    Single core
    Surface treatment:
    Polished & Sandblast
    Seal o-ring:
    Silastic/NBR/EPDM/Viton
    Top cap installed type:
    Clamp type
    Connector type:
    222/226/DOE
    Inlet & Outlet type:
    Internal thread
    Packaging method:
    Export standard box
    After-sales Service Provided:
    Online support

    Packaging & Delivery

    Selling Units:
    Single item
    Single package size:
    50X25X25 cm
    Single gross weight:
    6.000 kg
    Package Type:
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns: Packaging: Export standard box/As required
    Lead Time :
    Quantity(Units) 1 - 10 11 - 100 >100
    Est. Time(days) 7 15 To be negotiated
    Product Description
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 7

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns:

    LVYUAN  stainless steel cartridge filter housing offers wide range of flow capacities & contaminant holding capacities.

    Cartridge filters are normally used as polishing filter in almost all process industries. Cartridge filter is constructed of filter

    housing, filter cartridges,tube sheet, positive sealing arrangement for cartridge depending upon type of cartridge& choice of end connections. Positive sealing arrangement for cartridge filter assures no particle migration or fiber migration, even after high differential pressures.

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 9
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 11
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 13
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 15
    Model No.
    Drain
    Vent
    In & Out
    Body diameter
    Thickness
    LY-FL-SC-L1
    1/4"
    1/4"
    1/2"  3/4"  1"
    89mm
    1mm-2mm
    LY-FL-SC-L2
    1/4"
    1/4"
    1/2" 3/4" 1"
    89mm
    1mm-2mm
    LY-FL-SC-L3
    1/4"
    1/4"
    1/2" 3/4" 1"
    89mm
    1mm-2mm
    LY-FL-SC-L4
    1/4"
    1/4"
    1/2" 3/4" 1"
    89mm
    1mm-2mm

    Features:

    1.Inlet & outlet size is 1/2", 3/4". 1" for easy installation.

    2. Working pressure 8kg/0.8Mpa, 10kg/1Mpa is supported.

    3. Use the tap water pressure to provide power, no power consumption.

    4. Wall-mounted, counter-top, very simple installation.

    5. It is suitable for using in the water mater switch, for the pre filtration system and RO system protection.

    6. Resistance to strong acid and alkali.

    7. Low cost, it fits different kind of filter elements.

    Structure:

    Housing material 304 or 316L stainless steel, the housing body through inside and outside polishing, it meets the sanitary grade.

    Inside with the silicone gasket, it can be applied to cold & hot water temperature.

    High pressure resistance, corrosion resistance.

    Detailed Images
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 17
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 19
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 21
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 23
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 25
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 27
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 29
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 31
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 33
    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 35
    Application

    1. Widely used in UF, RO, EDI security filtration and the end-filtration.

    2. Chinese herbal medicine, such as liquid filtration, biological agents extraction, purification and concentration.

    3. Electonics, semiconductor industry with high purity water preliminary filter, teminal filter.

    4. Oil field, chemical reagent, liquid organic products, high purity chemicals, strong medicine and other filtration.

    5. Drinking pure water, mineral water, fruit juice, tea, beverages, health drinks.

    6. Liquid, wine, beer, yellow wine and ther friut wine filtration, pure draft beer aseptic filtration.

    7. The life and procution waste water treatment and water recycling process of pre-treatment filtering or security filtering.

    8. Biological engineering, oil refining, printing and dyeing, testile industry water supply and waste water treatment, research and test filter, etc.

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 37

    BOTTLED WATER

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 39

    BEVERAGE & DRINKS

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 41

    BIOLOGY TECHNOLOGY

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 43

    RO WATER TREATMENT

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 45

    CHEMICAL INDUSTRY

    High polished single round SS304 316L 10 20 inch stainless steel housing filters with ss filter elements 5 microns 47

    POWER PLANT
