Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.

High quality water filter cartridge manufacturers for water 1

High quality water filter cartridge manufacturers for water 2

High quality water filter cartridge manufacturers for water 3

High quality water filter cartridge manufacturers for water

Inquiry

Overview

Quick Details

Place of Origin:: China

Brand Name:: Lvyuan/OEM

Model Number:: LY-PLF-01

Power (W):: 0

Voltage (V):: 0

After-sales Service Provided:: none

Warranty:: none

Type:: Reverse Osmosis

Certification:: GS

Use:: Household Pre-Filtration

Application:: Car, RV, Outdoor, Hotel, Garage, Commercial, Household

Power Source:: Manual

Name:: filter supplies element

Filter membrane material:: PP/PVDF/PTFE/PES/Nylon

Length:: 5 / 10 / 20 / 30 / 40 / 50 / 60 inch

Conector:: Fin/222/226/215/DOE/Thread

Micron:: 0.22/0.5/1/3/5/10/25/50/75/100/150

Sealing method:: Hot melting welding

Diameter:: 70mm/OEM

Inner Core:: PP/SS/OEM

MOQ:: Currently no limited

Supply Ability

Supply Ability:: 5000 Piece/Pieces per Week

Universal high quality filter supplies element for condensate water

Product Description

High quality water filter cartridge manufacturers for water 4

Product Name	Water treatment plant RO pleated filter 5 microns PP cartridge water filter with 10 20 30 40 inch length
Filtration media	PP/PTFE/PES/PVDF/Nylon
Support material	Polypropylene
Core & Structural components	Polypropylene
Inner core	PP/Stainless steel
Packing method	Polybag/Vacuum
Filtration precision	0.1μm, 0.2μm, 0.45μm, 0.65μm,0.8μm,1μm,2μm,3μm,5μm,10μm,20μm,25μm,30μm,50μm
Length	2.5", 5". 10", 20", 30", 40", 50", 60", OEM
Adaptor	215/222/226/Fin/Flat/Thread/OEM
Sealing method	Hot melting welding
Sealing gasket & O-ring material	Silicone rubber; Nitrile butadiene rubber, EPDM, Fluorine rubber.
Effect filtration area	≥0.6m²
Filter cartridge diameter	69mm
Max. working temperature	PP: 88℃,0.27Mpa； PTFE: 80℃, 0.173Mpa ；PES: 85℃, 0.28Mpa PVDF: 80℃, 0.173Mpa；Nylon: 49℃, 0.21Mpa
Max. positive differential pressure	0.42Mpa (25℃)
Max. back pressure differential pressure	0.28Mpa (25℃)
Sterilization conditions	121℃ 30min
Applications	Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;

High quality water filter cartridge manufacturers for water 6

PP melt blown water filter cartridge

Polypropylene melt blown filter cartridge or PP spun water filter, PP filter, PP filter cartridge is the most widely used filtration consumable products in domestic and industrial water treatment systems.

PP melt blown filter cartridges (PPF) are made of 100% pure polypropylene fiber, providing broad wide chemical compatibility.
Melt Blown sediment filter cartridge has strong pollutants holding capacity.

Polypropylene microporous membrane filter

PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications. They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of
feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns. The high surface area ensures long service life and low initial pressure drops.

High quality water filter cartridge manufacturers for water 8

Detailed Images

High quality water filter cartridge manufacturers for water 10

Groove surface PP sediment filter cartridges.

High quality water filter cartridge manufacturers for water 12

Flat surface PP sediment filter cartridge

High quality water filter cartridge manufacturers for water 14

215 222 226 Flat/Fin end cap PP filter, code 0 3 6 7 8 9 available.

High quality water filter cartridge manufacturers for water 16

DOE opened pleated filter

High quality water filter cartridge manufacturers for water 18

OEM customized size filter

High quality water filter cartridge manufacturers for water 20

Different end caps pleated filter

High quality water filter cartridge manufacturers for water 22

PP melt blown filter cartridge with 1 2 3 layers for option

High quality water filter cartridge manufacturers for water 24

PP shell Polypropylene melt blown filter cartridge

High quality water filter cartridge manufacturers for water 26

Customize PP core or stainless steel shell/core pp filter cartridge

High quality water filter cartridge manufacturers for water 28

Application

High quality water filter cartridge manufacturers for water 30

RO WATER TREATMENT

High quality water filter cartridge manufacturers for water 32

BOTTLED MINERAL WATER

High quality water filter cartridge manufacturers for water 34

CHEMICAL TECHNOLOGY FILTRATION

High quality water filter cartridge manufacturers for water 36

BEER & BEVERAGE FILTRATION

High quality water filter cartridge manufacturers for water 38

PETROCHMICAL INDUSTRY

High quality water filter cartridge manufacturers for water 40

SEA DESALINATION WATER EQUIPMENT

Packing & Delivery

High quality water filter cartridge manufacturers for water 42

High quality water filter cartridge manufacturers for water 44

High quality water filter cartridge manufacturers for water 46

Container for shipment

High quality water filter cartridge manufacturers for water 48

Container for shipment

Certifications

High quality water filter cartridge manufacturers for water 50

High quality water filter cartridge manufacturers for water 52

High quality water filter cartridge manufacturers for water 54

Our Company

High quality water filter cartridge manufacturers for water 56

High quality water filter cartridge manufacturers for water 58

Let's Make Custom Water Filter Cartridge For You Now.

Lvyuan is highly recommended for our cartridge filter manufacturer in addition to our cartridge filter manufacturer. All its elements are made with FDA compliant material for food and beverage contact. Lvyuan not only appreciates the water filter cartridges but also a service commitment. All its elements are made with FDA compliant material for food and beverage contact.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
