Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
Lvyuan activated carbon sintered plastic filter rod for sea water desalination
- Adhering to the service concept to be customer-oriented, Lvyuan Water Purification Equipment wholeheartedly provides customers with high-quality products and professional services.
1. Lvyuan sintered metal filter elements is manufactured in compliance with the industry defined norms and guidelines.
2. The function of the product has been continually improved by our dedicated R&D team.
3. The quality testing unit is built under strict quality control parameters.
4. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. will strictly inspect product package to ensure sintered plastic filter will be totally safe during transportation.
5. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. applys the advanced technology so flexibly that it can guarantee both quality and quantity while finishing the production tasks.
Product Feature
◪ Uniform structure, narrow pore size distribution, and high separation efficiency.
◪ High porosity, the resistance of filtration less, and the penetration efficiency is high.
◪ High temperature resistant, it can be normally used below in 280 degree.
◪ Good chemical stability, acid & alkali corrosion resistance, and oxidation resistance.
◪ Good mechanical performance, it can have the suction filtration and press-filtration, simple operation.
◪ Low differential pressure, the area of cover is small, and large water flow rate;od mechanical performance, it can have the suction filtration and press-filtration, simple operation.
◪ Strong antimicrobial ability, no microbes.
◪ The finished-products technology is good, the overlength of overall length can be reached to 1000mm.
◪ It can be on-line regeneration, easy to clean, and long service life.
◪ No particles fall off, it will not make the concentrate form secondary pollution, it conforms to be food hygiene and pharmaceutical GMP requirements.
Product Parameter
| Fiter Cartridge dimensions | |
| Length | 5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm） |
| Diameter | Ø22, 30, 50, 60, 70, 80, 100, 120mm |
| Other dimensions | Customized by customer’s request. |
| Material of constructions | |
| Filter media | Titanium |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, 215, 222, 226, M20, M30, M42 or as request. |
| Sealing material | Silicone, NBR, EPDM, Fluoro rubber, etc |
| Performance | |
| Removal rate | 0.1, 0.45, 1, 3, 5, 10,20, 30, 40, 50, 100um |
| Porosity | 28-50% |
| Temperature Tolerance | ≦ 300℃ wet |
| Permeability | 0.02-20L/cm2 min Pa |
| Maximum Operating Pressure differential | 6.0 bar |
| Flow rate (L/H) | 180, 200, 250, 280, 300, 350, 500, 800, 1000, 1500, 1600 |
◆◆Pure water flow rate reference table: the initial value of 10'' sintered titanium cartridge (P=0.2 MPa, 1cP, 25℃)
| Micron rate (μm) | 0.2 | 0.45 | 1 | 2 | 3 | 5 | 10 | 20 | 30 |
| Flow rate (L/H) | 180 | 200 | 250 | 280 | 300 | 350 | 500 | 800 | 1000 |
Product Details
Product Applications
Company Features
1. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is able to design and manufacture a range of sintered plastic filter.
2. Due to our market expanding strategy and strong performance, we have acquired trust and developed long-term partnerships in North America, South East Asia, and Europe.
3. We strive for a culture of integrity in our people, partners, and suppliers. To this end, we have established a dedicated ethics and compliance program to ensure that ethical and compliant behavior is deeply embedded throughout the company. Please contact. In our company, sustainability is no longer a lofty ideal. We will optimize resource utilization, improve eco-benefits, offer green products and contribute to society to enhance corporate image and sustainability. Please contact. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is committed to improving quality and image as well as brand reputation. Please contact.
