Company Advantages1. It is clear that with the feature of 20 micron pleated water filter , our pleated water filter cartridge will attract more attention than before. It is available in a wide selection of micron ratings from 1 to 100 μm
2. By introducing constantly advance technology, combined with advantages of 20 micron pleated water filter , pleated water filter cartridge are very popular in oversea markets. The filter media is thermally bonded to prevent fiber release while providing consistent flow rates
3. The product is not subject to paint-shedding nor its finish being scratched mainly thanks to its finely surface treatment. With a large number of tapered fixing holes inside, it has a high dirt holding capacity
4. The product features a superior ergonomic design. The size and graphical interface of this product are designed to be user-friendly. There is different porosity across the depth of its filter medium
DOE end caps pleated filter cartridge for Polypropylene
The PP pleated filter cartridge uses pleated polypropylene fiber membrane as filtration media.
The PP Polypropylene cartridge is an advanced fixed intensive filter and available in a wide range of retention rating from 0.1μm to 60μm. The pore size is not affected by the vibration of feeding pressure. Due to its unique low differential pressure, high flow volume, excellent filtration capability attracted many customers..
Detail of Pleated filter cartridge
Jumbo / High flow rate Pleated Filter Cartridge
End Cap for pleated filter cartridge
7 Round 30 inch Stainless Steel cartridge filter housing
1. Electronic industry: RO reverse osmosis water system prefiltration, deionized water system prefiltration.
2. Food industry: filtration of beverage, beer and mineral water.
3. Chemical industry: filtration of organic solvent and ink.
4. Pharmaceutical industry: filtration of pharmaceuticals, biologicals, serum products, compressed air and gas.
5. Others: filtration of plating solution, process fluids, photoresist and magnetic media
Filter Media Option | | PTFE filter cartridge | Nylon 6 filter cartridge | PES filter cartridge | PVDF filter cartridge |
Length | 5, 10, 20, 30, 40 | 5, 10, 20, 30, 40 | 5, 10, 20, 30, 40 | 5, 10, 20, 30, 40 | 5, 10, 20, 30, 40" |
Micron Rate | 0.1, 0.2, 0.45, 0.65, 0.8, 1, 2, 3, 5, 10, 20, 25, 30, 50, 60 micron | 0.2, 0.45 micron | 0.2, 0.45, 0.65, 1 micron | 0.1, 0.2, 0.45, 0.65 micron | 0.2, 0.45 micron |
End Cap | DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat | DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat | DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat | DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat | DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat |
Inner Diameter | 28mm | 28mm | 28mm | 28mm | 28mm |
Outer Diameter | 68mm (can be customized) | 68mm (can be customized) | 68mm (can be customized) | 68mm (can be customized) | 68mm (can be customized) |
Jumbo Size | ID: 30mm, OD: 110~115mm | ID: 30mm, OD: 110~115mm | ID: 30mm, OD: 110~115mm | ID: 30mm, OD: 110~115mm | ID: 30mm, OD: 110~115mm |
Gasket/O ring material | Silicon/EPDM/NBR/Viton/Teflon | Silicon/EPDM/NBR/Viton/Teflon | Silicon/EPDM/NBR/Viton/Teflon | Silicon/EPDM/NBR/Viton/Teflon | Silicon/EPDM/NBR/Viton/Teflon |
Effective filtration area | 0.4-0.7m² | ≥0.72m² | ≥0.6m² | ≥5m² | ≥0.72m² |
Max.working pressure difference | 0.42Mpa at 25℃ | 0.42Mpa at 25℃ | 0.42Mpa at 25℃ | 0.42Mpa at 25℃ | 0.42Mpa at 25℃ |
Max.back pressure | 0.28Mpa at 60℃ | 0.35Mpa at 60℃ | 0.35Mpa at 25℃ | 0.21Mpa at 25℃ | 0.21Mpa at 25℃ |
Max. working temperature | 88℃ at 0.28Mpa, 60℃ at 0.42Mpa | 142℃ at 0.276Mpa | 49℃ at 0.21Mpa | 140℃ at 0.28Mpa | 80℃ at 0.173Mpa |
Sterilizing temperature | 121℃, 30mins | 121℃, 30mins | 121℃, 30mins | 121℃, 30mins | 121℃, 30mins |
String Wound filter cartridge
CTO Activated Carbon filter cartridge
Guangzhou Lvyuan Water Purification Equipment Co.,Ltd is a comprehensive enterprise. As a Leader Manufacturer in Guangzhou city, our competitive product lines including:
1. All kinds of Filter Cartridges, Pleated / Melt Blown / Sintered etc.
2. Cartridge filter housings and bag filter housings
3. RO, UF, MBR water purifier and equipment
4. Water treatment equipments
5. Many kinds of Water purifiers and equipments, water softners, and more.
We devote to filtration development for more than 10 years. We can supply advanced technical support and solution for all of our customers during and after warranty period.
1. Q: Are you factory?
A: Yes, we are the professional manufacturer with continuous and improved R & A production, sales and service supply. We will always provide the best technical service support to our clients both in and after warranty period.
2. Q: How to get a quotation?
A: In order to send you our best price, please kindly inform us detail product parameters and order quantity.
3. Q: Can I get your products with our logo and design?
A: Customized service is available. We can OEM or ODM with your logo.
4. Q: What's the MOQ ?
A: We can offer the quantity you required, as we don't dictate MOQ terms.
The product is designed to make tasks easier and relieve workers' fatigue. It is outstanding in improving overall efficiency and productivity. It will trap larger particles in the outer layers and capture smaller particles in the deep layer.
Because the product can greatly increase productivity, increases manufacturers' flexibility by letting them add and subtract contract workers. It will trap larger particles in the outer layers and capture smaller particles in the deep layer.
Company Features1. Our factory is well equipped. It helps us to be flexible on product designing, as well as on prototyping or medium and large serial production.
2. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is striving to become a world-class manufacturer of pleated water filter cartridge . Check it!
