Lvyuan nylon pleated filter with stainless steel for industry

Start Port:
Guangzhou
Production Capacity:
500 units/Month
Place of Origin:
Guangdong ,China
Payment:
T/T, Alibaba Trade Assurance, paypal
MOQ:
10pcs
Model:
LY-PL-PP
Delivery Time:
Within 7 working days
Certification:
SGS, ISO 9001
Brand:
OEM/Lvyuan
Inquiry

Lvyuan nylon pleated filter with stainless steel for industry 11

PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications.

They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns.

The high surface area ensures long service life and low initial pressure drops. All cartridges hardware components are made from high purity polypropylene materials for use in critical process application. All the Cartridges are manufactured and assembled in a clean room environment to minimized the possibility of contamination.

This type of cartridges are available in a wide range of configurations to fit most commercially available filter housings.


  Product Feature

  • ◪    Excellent chemical compatibility. Suitable for filtering organic solvents, acid bases.

  • ◪   The multi layers PP membrane structure enables a graded filtration pore sizes and increases the dirt-holding capacity of the PP pleated water cartridge filters.

  • ◪   Large flow volume, low differential pressure and long service life.

  • ◪   Hydrophilic membrane with high flow.

  • ◪   Pleated design increased the filtration area for deep filtration.

  • ◪   Application of thermal-bonding technique, strong and no any pollution.

  • ◪   Full rage of removal microns ratings.

  • ◪   Graded pore density for high dirt holding capacity.

  • ◪   Common use in clean and sterilize with cabinet & steam with high pressure.


Product Parameter



Filter mediaPP/Polypropylene
SupportPP/Polypropylene
Core/End capPP/Polypropylene
Seal materialSilicone/EPDM/NBR/Viton/Teflon
Outer diameter2.7'' , customized
Length9.75'', 10'',  20'', 30'', 40'' customized
End capDOE, 215, 222, 226, FIN, FLAT, Stainless steel, or customized.
Filtration area0.4-0.7m² (10'')
Max.operating temperature88℃, 0.28Mpa. 60℃, 0.42Mpa.
Micron rating(μm)0.1, 0.2, 0.45, 0.65, 1, 2, 3, 5, 10, 20, 25, 30, 50, 60



Product Details



Lvyuan nylon pleated filter with stainless steel for industry 12

part.1
Polypropylene end caps are thermally bonded to the media packs eliminating any need for adhesives which might react with or contaminate critical process fluids. Strong and no any pollution.
Lvyuan nylon pleated filter with stainless steel for industry 13

part.2
High efficiency 100% all polypropylene cartridges with hard polypropylene support inner core and outer core. We provide customized sizes to meet different customers’ required.
Lvyuan nylon pleated filter with stainless steel for industry 14

part.3
Different end caps to fits any filter housing and filtration industry, 100% all pure polypropylene pleated material without any organic binder.
Lvyuan nylon pleated filter with stainless steel for industry 15

part.4
DOE 20 inch PP material pleated filter cartridge with EPDM gasket, graded-porosity multi-layer.



Product Applications



Lvyuan nylon pleated filter with stainless steel for industry 16

Reverse osmosis water system prefiltration


Lvyuan nylon pleated filter with stainless steel for industry 17
Filtration of beverage
Lvyuan nylon pleated filter with stainless steel for industry 18
Filtration of mineral water
Lvyuan nylon pleated filter with stainless steel for industry 19
Filtration of organic solvent & ink
Lvyuan nylon pleated filter with stainless steel for industry 20
Filtration of pharmaceuticals
Lvyuan nylon pleated filter with stainless steel for industry 21
Filtration of biological

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
