Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
Lvyuan pes pleated water filter cartridge replacement for food and beverage
Start Port:
Guangzhou
Production Capacity:
500 units/Month
Place of Origin:
Guangdong, China
Payment:
T/T, Western Union, MoneyGram, Alibaba Trade Assurance, paypal
MOQ:
10pcs
Model:
LY-PL-PTFE
Delivery Time:
Within 7 working days
Certification:
SGS, ISO 9001
Brand:
LVYUAN
Product Comparison
Lvyuan Water Purification Equipment carries out strict quality monitoring and cost control on each production link of water filter cartridges, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.Compared with products in the same category, water filter cartridges's core competencies are mainly reflected in the following aspects.
1. The designed of Lvyuan high efficiency pleated filters is sophisticated. It is developed by professionals who have been involved in the characterization, Mechanical design, and development of advanced technology products for years.
2. The function of our pleated water filter cartridge is diverse.
3. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. can send free samples if needed by customers.
PTFE membrane cartridge filter is constructed of imported natural
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
Product Feature
◪ Excellent hydrophobic performance, the water erosion is more resistant than the common PVDF membrane.
◪ Withstand water shock, back pressure and repeated high temperature sterilization.
◪ 100% bacterial retention & effective filtration to 0.2 μm particle.
◪ 100% integrity tested.
◪ It is constructed of 2 kinds of hot welding materials(PTFE & PP), not any adhesives, clean & stable, meet the high standards of pharmaceutical industry.
Product Parameter
| Product Name | 10 inch PTFE membrane pleated filter cartridge with stainless steel 222 |
| Filter media | PTFE membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7‘’(69mm) |
| Length | 9.75'', 10'', 20'', 30'', 40'', Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.72m² |
| Max.operating temperature | 80℃, 0.173Mpa |
| Micron rating(μm) | 0.2, 0.45 |
Product Details
part.1
It is constructed of 2 kinds of hot welding materials(PTFE & PP), no any adhesives,
clean & stable.
part.2
DOE double opened PTFE membrane filter with PTFE gasket. It is a good choice for the pharmaceutical and ohter strict applications.
part.3
The adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution.
part.4
Different length & variety end cap are optional.
Product Applications
Reverse osmosis water system prefiltration
Electronic l industry
Filtration of mineral water
Filtration of organic solvent & ink
Filtration of pharmaceuticals
Filtration of biological
Company Features
1. Thanks to its focus on design and manufacture, Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has been recognized as a reliable manufacturer of high efficiency pleated filters .
2. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has improved its R&D environment for pleated water filter cartridge .
3. In accordance with the principle of prudent operation, Guangzhou Lvyuan Water Purification Equipment Co., Ltd. will make no effort to increase its competitiveness. Get more info! Guangzhou Lvyuan Water Purification Equipment Co., Ltd. adhere to pleated polypropylene filter cartridge and make pleated filter sizes as its eternal tenet. Get more info!
