Lvyuan pes pp pleated filter cartridge with stainless steel for diagnostics
- Lvyuan Water Purification Equipment always puts customers first and treat each customer sincerely. Besides, we strive to meet the requirements of customers and solve their problems duly.
1. The manufacturing of Lvyuan pp pleated filter cartridge adopts the assembly line system. The product will be sent on to the next step in the production process after it is inspected by QCs who have years of experience working in the shoemaking factory.
2. The product has the advantage of stable mechanical properties. Having been treated under extremely cold temperatures, its mechanical components are tensile enough to withstand extreme industrial conditions.
3. Good environment of production zone and workshop is one of the conditions for improving the pleated water filter cartridge quality.
PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications.
They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns.
The high surface area ensures long service life and low initial pressure drops. All cartridges hardware components are made from high purity polypropylene materials for use in critical process application. All the Cartridges are manufactured and assembled in a clean room environment to minimized the possibility of contamination.
This type of cartridges are available in a wide range of configurations to fit most commercially available filter housings.
Product Feature
◪ Excellent chemical compatibility. Suitable for filtering organic solvents, acid bases.
◪ The multi layers PP membrane structure enables a graded filtration pore sizes and increases the dirt-holding capacity of the PP pleated water cartridge filters.
◪ Large flow volume, low differential pressure and long service life.
◪ Hydrophilic membrane with high flow.
◪ Pleated design increased the filtration area for deep filtration.
◪ Application of thermal-bonding technique, strong and no any pollution.
◪ Full rage of removal microns ratings.
◪ Graded pore density for high dirt holding capacity.
◪ Common use in clean and sterilize with cabinet & steam with high pressure.
Product Parameter
| Filter media | PP/Polypropylene |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/NBR/Viton/Teflon |
| Outer diameter | 2.7'' , customized |
| Length | 9.75'', 10'', 20'', 30'', 40'' customized |
| End cap | DOE, 215, 222, 226, FIN, FLAT, Stainless steel, or customized. |
| Filtration area | 0.4-0.7m² (10'') |
| Max.operating temperature | 88℃, 0.28Mpa. 60℃, 0.42Mpa. |
| Micron rating(μm) | 0.1, 0.2, 0.45, 0.65, 1, 2, 3, 5, 10, 20, 25, 30, 50, 60 |
Product Details
Product Applications
Reverse osmosis water system prefiltration
Company Features
1. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is the pioneer of pp pleated filter cartridge research and development in this industry.
2. Guangzhou Lvyuan Water Purification Equipment Co., Ltd.'s R&D strength and sufficient technical reserve can meet various demands of the customers.
3. We adopt the concept of pleated filter sizes to invite all the friends to come forward together in pleated water filter cartridge industry. Get more info! Lvyuan's work adheres to the policy of 20 micron pleated water filter development. Get more info! Lvyuan enjoys a high reputation in pleated filter manufacturers industry for its tenet of pleated polypropylene filter cartridge . Get more info!
