Lvyuan pleated filter manufacturer for food and beverage
-
v s
1. Lvyuan pleated filter must be tested to be in compliance with general standards. It has been tested for machinery directive, operation safety, and life expectancy.
2. The product has outstanding performance and stable and reliable quality.
3. Owing to the years of production experience, the product is guaranteed to be of superior quality.
The PES pleated filter cartridge is constructed of imported polyethersulfone(PES) membrane media and non-woven support materials.The material of cage core and end caps is polypropylene. Absolute precision polyethersulfone membrane (PES) filter cartridges, adapters are thermally welded with media without using any glue, not any pollution.
The PES filter cartridge is ideal for critical prefiltration to sterilise applications and final filtration in a broad range of demanding non-sterile application. The inherently hydrophilic membrane contains no surfactant or wetting agents, which leads to effective filtration and flow rates
Due to its wide range of PH values and lower adsorption to protein than nylon membrane, it has become the preferred filter cartridge for final filtration in pharmaceutical, food and chemical industries.
Product Feature
◪ The product offers excellent retention efficiency and extended on-stream life making it an ideal filter for the clarification of beer, wine and bottled water.
◪ Excellent performance of chemical compatibility.
◪ High temperature resistance, Acid & Alkali resistance.
◪ Hydrophilic membrane with high flow.
◪ Non-fiber releasing, it meets the high standard pharmaceutics & food industry requirements.
◪ PES pleated cartridge filters are integrity tested during production to assure performance and consistency.
Product Parameter
| Product Name | 0.2 μm PES membrane pleated cartridge filter 5 inch |
| Filter media | PES(Polyethersulfone) |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7'' (69mm) |
| Length | 5'', 9.75'', 10'', 20'', 30'', 40'', Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.6m² |
| Max.operating temperature | ≤140℃, 0.28Mpa |
| Micron rating(μm) | 0.1, 0.2, 0.45, 0.65 |
Product Details
Product Applications
Medicine
Company Features
1. With rich industry experience, Lvyuan does well in home and abroad market.
2. Lvyuan becomes increasingly more popular and famous because of its high-quality pleated filter .
3. We help clients with all aspects with product R&D– from concept and design to engineering and testing, to strategic sourcing and freight forwarding. Ask online! Through treating employees fairly and ethically, we fulfill our social responsibility, which is especially true for disabled people or ethnic people. Ask online! Our company bears social responsibilities. The physical plant of our factory presents some of the easiest, most cost-efficient ways to reduce waste. We have three aspirational goals: to create zero waste, operate with 100% renewable energy and sell products that sustain our resources and the environment.
