Lvyuan pleated water filter cartridge supplier for sea water desalination1
-
v s
1. The structural optimization for the body frame of pleated water filter cartridge is achieved in pp pleated filter cartridge produced by Guangzhou Lvyuan Water Purification Equipment Co., Ltd..
2. It has good strength. Its elements are strong enough to sustain all the forces it is designed for so that it is not damaged or permanently deformed during its lifetime.
3. This product is not afraid of temperature variations. Its materials are pre-tested to ensure stable physical and chemical properties under different temperatures.
4. This product has a good market reputation thanks to its huge market prospects.
PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications.
They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns.
The high surface area ensures long service life and low initial pressure drops. All cartridges hardware components are made from high purity polypropylene materials for use in critical process application. All the Cartridges are manufactured and assembled in a clean room environment to minimized the possibility of contamination.
This type of cartridges are available in a wide range of configurations to fit most commercially available filter housings.
Product Feature
◪ Excellent chemical compatibility. Suitable for filtering organic solvents, acid bases.
◪ The multi layers PP membrane structure enables a graded filtration pore sizes and increases the dirt-holding capacity of the PP pleated water cartridge filters.
◪ Large flow volume, low differential pressure and long service life.
◪ Hydrophilic membrane with high flow.
◪ Pleated design increased the filtration area for deep filtration.
◪ Application of thermal-bonding technique, strong and no any pollution.
◪ Full rage of removal microns ratings.
◪ Graded pore density for high dirt holding capacity.
◪ Common use in clean and sterilize with cabinet & steam with high pressure.
Product Parameter
| Filter media | PP/Polypropylene |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/NBR/Viton/Teflon |
| Outer diameter | 2.7'' , customized |
| Length | 9.75'', 10'', 20'', 30'', 40'' customized |
| End cap | DOE, 215, 222, 226, FIN, FLAT, Stainless steel, or customized. |
| Filtration area | 0.4-0.7m² (10'') |
| Max.operating temperature | 88℃, 0.28Mpa. 60℃, 0.42Mpa. |
| Micron rating(μm) | 0.1, 0.2, 0.45, 0.65, 1, 2, 3, 5, 10, 20, 25, 30, 50, 60 |
Product Details
Product Applications
Reverse osmosis water system prefiltration
Company Features
1. Guangzhou Lvyuan Water Purification Equipment Co., Ltd., with years of designing and production expertise, is among the top professional providers of pp pleated filter cartridge . We've been offering products and production services for years.
2. We have a loyal and strong customers base who have been maintaining business relationships with us for years. This is because we spend many efforts in developing innovative and suitable products for them and always offer our best services.
3. We recognize our responsibility to reduce our contribution to global climate change. We work to conserve energy, invest in renewable sources of energy, and reduce our greenhouse gas (GHG) emissions. We will make the business scale double in the next coming years through innovation drive. We will strengthen the R&D ability in offering product diversity. We try to go green in all our business activities. We will use less power and water than conventional production methods, and recycle reusable materials to upgrade our packaging way.
