Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
Lvyuan water filter cartridge factory for sale3
1. Some components or parts of Lvyuan water filter cartridge for water filter system are sourced from suppliers who have a reliable and good reputation in catering tools industry. These suppliers all hold food safety certifications. Customized end cap configurations are available to fit specific requirements
2. A huge benefit of this product for business owners is its incredible safety. This will minimize the risks of getting injured all the time. The star-shaped ring seal makes the filter element easy to disassemble and maintain
3. The product is resistant to aging. The organic rubber materials used are tested at ambient (73°F), and most of these will take a permanent set at elevated temperatures. It has found a variety of applications ranging from industrial, chemical process, food and beverage, cosmetics and water
4. The product is water resistant. Its fabric is capable of handling a lot of exposure to moisture and has good water penetration. Its unique density gradient construction maximizes efficiency and minimizes pressure drop
5. The product has the advantage of spalling resistance. It has the ability to undergo certain sharp temperature variations without failing. There is different porosity across the depth of its filter medium
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
Product Feature
◪ Excellent hydrophobic performance, the water erosion is more resistant than the common PVDF membrane.
◪ Withstand water shock, back pressure and repeated high temperature sterilization.
◪ 100% bacterial retention & effective filtration to 0.2 μm particle.
◪ 100% integrity tested.
◪ It is constructed of 2 kinds of hot welding materials(PTFE & PP), not any adhesives, clean & stable, meet the high standards of pharmaceutical industry.
Product Parameter
| Product Name | 10 inch PTFE membrane pleated filter cartridge with stainless steel 222 |
| Filter media | PTFE membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7‘’(69mm) |
| Length | 9.75'', 10'', 20'', 30'', 40'', Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.72m² |
| Max.operating temperature | 80℃, 0.173Mpa |
| Micron rating(μm) | 0.2, 0.45 |
Product Details
Product Applications
Reverse osmosis water system prefiltration
Company Features
1. water filter cartridge enjoys good quality performance for the application of finest technology.
2. We think highly of ethical standards. Under this principle, we always do fair trade, refuse to manipulate or falsely advertise to our customers or potential consumers, as well as vicious business competition such as bidding up the price.
