    Overview
    Quick Details
    Condition:
    New
    Applicable Industries:
    Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
    After Warranty Service:
    Online support
    Local Service Location:
    none
    Showroom Location:
    none
    Video outgoing-inspection:
    Provided
    Machinery Test Report:
    Provided
    Marketing Type:
    Ordinary Product
    Warranty of core components:
    1 Year
    Core Components:
    Pressure vessel
    Place of Origin:
    Guangdong, China
    Brand Name:
    LVYUAN/OEM
    Warranty:
    1 Year
    After-sales Service Provided:
    Online support
    Name:
    oil filter element cartridge
    Filter membrane material:
    Polypropylene/Glass fiber/PET
    Length:
    5 / 10 / 20 / 30 / 40 / 50 / 60 inch
    Conector:
    DOE, 222/Flat, End
    Micron:
    1 ~ 100um
    O-ring material:
    EPDM/Silicone/NBR
    Sealing method:
    All-in-One
    Diameter:
    64mm/Customized
    Inner Core:
    Plastic PP
    MOQ:
    Currently no limited
    Product Description
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 7
    Product Name
    OD 2.5 inch 222/fin 10 microns pleated fiber material oil filter element cartridge for oil filed 40 inch filter treatment
    Length:
    10"/20"/30"/40"/50"
    OD:
    64mm
    ID:
    28mm
    Filter membrane media:
    Glass fiber, Polypropylene PP, PET
    Seal Material:
    EPDM, Silicone, NBR, Viton
    End cap material:
    222+FIN END; DOE; 222+Flat End
    Center core:
    Polypropylene PP
    Outer cage:
    Polypropylene PP, blue/red/white colors optional.
    Microns rating:
    1um, 2um, 3um, 5um, 10um, 20um, 25um, 30um, 50um, 75um,100um
    Operating pressure:
    Withstand differential pressure up to 60psi(4bar) at ambient temperature.
    Differential pressure is 35psi (2.5bar) up to 52℃.
    Service condictions:
    5 bar at 20℃; 3bar at 65℃
    Applications:
    RO water treatment prefiltration;
    Electronic;
    Oil & Gas liquid;
    Petroleum industry.
    MOQ
    50pcs/Box, 25pcs/Box

    Polypropylene PP/Fiberglass/PET pleated filter cartridge

    Guangzhou Lvyuan Water Purification Equipment Co., Ltd., we manufacture in a wide range of sizes and microns options filter elements and fits to different specification of filter housings. This type of pleated cartridge filter has superior flow characteristics with very low pressure drop compared to depth media of similar microns rating. It has large filtration area and design, allow the use of a reduced number of cartridges, high dirtholding capacity and long lifetime. Fully thermal welded construction can be used safely on high temperature oily water, solvents, acid and diesel.

    Features:

    1. To fit into different standard sizes water filter cartridge housing.
    2. High dirtholding capacity and high flow rate.
    3. Large capacity filtration area and depth filtration provides a long lifetime of pleated cartridge water filter.
    4. Low filter cartridges replacement cost, because of the large filter area to reduce labor costs to change.
    5. The glass fiber media can be used safely on the high temperature liquid water, diesel, oily liquid, chemical solvents, acid and alkali.
    Related Products

    Pleated PP/PES/PTFE/PVDF/Nylon membrane filter for water/air filtration treatment:

    Microporous pleated filter element, the main filter material is : Polypropylene, Hydrophobic PTFE, Hydrophilic PTFE,Polyether sulfone, Nylon, etc.
    Most of the raw materials are imported from abroad.Pleated filter element is a kind of deep filtration filter,it is usuaslly used as liquid overheating,clarification, filtration and terminal filter.
    It has the following characteristics: the superfine polypropylene fiber membrane as the filtration medium, low pressure differential, high flux, good filtration precision, lower economic cost.
    The whole structure of polypropylene, end cover, housing and center pole adopts polypropylene material; It adopts the hot melt welding process, PP and PP melt bonding,without any binder.
    It has wide range of chemical compatibility, and also has a series of pore size and form a variety of interface.Material: Pleated filter, Support layer, End-cover, Inside & Outside cylinder are polypropylene.
    Welding: It adopts the uniquehot melting methods, no glue, no foreign body fall off.
    Typical use: Pharmaceutical, Food, Chemical, Electronics, Environmental protection, etc.
    Microporous membrane pleated filter cartridge main features: High interception rate, high liquidity, low pressure differential and a wide range of chemical compatibility;
    The production process adopts unique hot melting process technology, no any adhesive, no foreign body release.
    It can meet the food,beverage, beer, chemical, pharmaceutical and other industries production requirements.

    Polypropylene microporous membrane filter

    PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications. They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of
    feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns. The high surface area ensures long service life and low initial pressure drops.

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 9
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 11

    PTFE membrane pleated filter

    Hydrophobic PTFE filter

    The filter medium is Hydrophobic PTFE microporous membrane filter: Strong hydrophobicity,
    High holding rate, excellent chemical resistance and thermal stability, good strength, impact resistance of the forward & reverse pressure.


    Hydrophilic PTFE filter

    The filter element medium for hydrphilic PTFE microporous membrane filter: The hydrophilic stability, high entrapment rate, excellent chemical resistance thermal stability, good strength, impact resistance of the forward & reverse pressure.

    Polyether Sulphone PES Pleated Filter

    The PES pleated filter cartridge is constructed of imported polyethersulfone(PES) membrane media and non-woven support materials.The material of cage core and end caps are polypropylene.Adapters are thermally welded with media without using any glue, no any pollution. The PES filter cartridge is ideally suited for critical prefiltration in sterilizing applications and final filtration in a broad range of demanding non-sterile application, the inherently hydrophilic membrane contains no surfactant or wetting agents, which results in good filtration and flow rates.

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 13
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 15



    Nylon N66 pleated membrane filter cartridge

    The filter medium is hydrophilic nylon microporous membrane filter, It is composed by nylon membrane and the polypropylene support material hot melting, it is no dung, also applicable for the strict chemical and pharmaceutical industries.

    PVDF pleated cartridge filter

    The PVDF pleated cartridge filter is constructed of imported natural hydrophobic polyvinylenedifluoride(PVDF) membrane media and non-woven support materials. The adaptors are thermally welded with media without using any glue, no any pollution.

    High filtration microns, high flow rate, better hydrophobicity, sterilization at high temperature as well as chemical resistance. It is widely used in gas or liquid pre-filtration and widely used in final filtration.

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 17
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 19

    Jumbo pleated membrane filter cartridge

    The big jumbo pleated filter cartridge is constructed of deep polypropylene membrane, melt blown polypropylene, hydrophilic PES & PTFE. The non-woven support materials. This filter cartridges design increased the effective filtration area, not only can reduct the filter cartridges quantity, but also it can make the smaller housing size. Big flow rate and long service life, lower cost and human cost. The size is divided into 2 kinds of size: 83mm diameter & 131mm diameter. Adaptors are thermally welded with media without using any glue, no any pollution and droppings. Clean & stable, each filter cartridge has passed strict testing by 100% integrity.

    Product Name
    Pleated PP/PES/PTFE/PVDF/Nylon membrane filter for water/air filtration treatment
    Filtration media
    PP/PTFE/PES/PVDF/Nylon
    Support material
    Polypropylene
    Core & Structural components
    Polypropylene
    Inner core
    PP/Stainless steel
    Packing method
    Polybag/Vacuum
    Filtration precision
    0.1μm, 0.2μm, 0.45μm,  0.65μm,0.8μm,1μm,2μm,3μm,5μm,10μm,20μm,25μm,30μm,50μm
    Length
    2.5", 5". 10", 20", 30", 40", 50", 60", OEM
    Adaptor
    215/222/226/Fin/Flat/Thread/OEM
    Sealing method
    Hot melting welding
    Sealing gasket & O-ring material
    Silicone rubber; Nitrile butadiene rubber, EPDM, Fluorine rubber.
    Effect filtration area
    ≥0.6m²
    Filter cartridge diameter
    69mm
    Max. working temperature
    PP: 88℃,0.27Mpa
    PTFE: 80℃, 0.173Mpa
    PES: 85℃, 0.28Mpa
    PVDF: 80℃, 0.173Mpa
    Nylon: 49℃, 0.21Mpa
    Max. positive differential pressure
    0.42Mpa (25℃)
    Max. back pressure differential pressure
    0.28Mpa (25℃)
    Sterilization conditions
    121℃ 30min
    Applications
    Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;
    Detailed Images
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 21

    DOE opened pleated filter

    The membrane's micron rating is optional. Options to order for this site include 0.03 to 0.45 microns in 10" to 40" length with either.

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 23

    OEM customized size filter

    Different length & variety end cap are optional.

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 25

    Different end caps pleated filter

    SDouble Open End (DOE), 222 or 226 end configurations, all come standard with EPDM/PTFE/SILICONE/TEFLON seals.

    Application
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 27

    RO WATER TREATMENT

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 29

    BOTTLED MINERAL WATER

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 31

    CHEMICAL TECHNOLOGY  FILTRATION

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 33

    BEER & BEVERAGE FILTRATION

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 35

    PETROCHMICAL INDUSTRY

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 37

    SEA DESALINATION WATER EQUIPMENT

    Packing & Delivery
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 39
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 41
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 43

    Container for shipment

    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 45

    Container for shipment

    Certifications
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 47
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 49
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 51
    Our Company
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 53
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 55
    Contact
    oil filedtreatment OD 2.5 inch 222/fin 5 microns pleated fiber material oil filter element cartridge 57




    Pls feel free to contact me:


    Ms. Vickie Yung

    Mob./Whatsapp/Wechat: +86 15975359293

    Skype: vickie9293

    People can invest in this product that can increase production efficiency and lower fixed costs such as time cost and labor cost. The inner support layer is closely connected to the filter material, making it of strong impact resistance. With the help of this product, time, money, and labor are significantly saved and reduced. This product can greatly reduce the production cost of the manufacturer. The inner support layer is closely connected to the filter material, making it of strong impact resistance.
