Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
pes pleated filter cartridge replacement for food and beverage
Start Port:
Guangzhou
Production Capacity:
500 units/Month
Place of Origin:
Guangdong, China
Payment:
T/T, Western Union, MoneyGram, Alibaba Trade Assurance, paypal
MOQ:
10pcs
Model:
LY-PL-PTFE
Delivery Time:
Within 7 working days
Certification:
SGS, ISO 9001
Brand:
LVYUAN
Product Comparison
cartridge housing manufacture is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.Compared with other products in the industry, cartridge housing manufacture has more obvious advantages which are reflected in the following aspects.
Product Details
With a focus on quality, Lvyuan Water Purification Equipment pays great attention to the details of water filter cartridges.water filter cartridges is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.
1. The production of Lvyuan pleated filter cartridge complies with international manufacturing standards. Thus, the use of toxic bleaches, dyes, and other chemicals is limited.
2. The product has passed all relative quality certificates.
3. Lvyuan introduces an efficient quality management system to effectively guarantee its quality.
4. Its application prospect becomes more and more extensive.
PTFE membrane cartridge filter is constructed of imported natural
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
Product Feature
◪ Excellent hydrophobic performance, the water erosion is more resistant than the common PVDF membrane.
◪ Withstand water shock, back pressure and repeated high temperature sterilization.
◪ 100% bacterial retention & effective filtration to 0.2 μm particle.
◪ 100% integrity tested.
◪ It is constructed of 2 kinds of hot welding materials(PTFE & PP), not any adhesives, clean & stable, meet the high standards of pharmaceutical industry.
Product Parameter
| Product Name | 10 inch PTFE membrane pleated filter cartridge with stainless steel 222 |
| Filter media | PTFE membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7‘’(69mm) |
| Length | 9.75'', 10'', 20'', 30'', 40'', Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.72m² |
| Max.operating temperature | 80℃, 0.173Mpa |
| Micron rating(μm) | 0.2, 0.45 |
Product Details
part.1
It is constructed of 2 kinds of hot welding materials(PTFE & PP), no any adhesives,
clean & stable.
part.2
DOE double opened PTFE membrane filter with PTFE gasket. It is a good choice for the pharmaceutical and ohter strict applications.
part.3
The adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution.
part.4
Different length & variety end cap are optional.
Product Applications
Reverse osmosis water system prefiltration
Electronic l industry
Filtration of mineral water
Filtration of organic solvent & ink
Filtration of pharmaceuticals
Filtration of biological
Company Features
1. It turns out to be efficient that seizing the precious chance to develop pleated filter cartridge is a wise choice to Lvyuan.
2. The company is now replete with a well-trained group of professionals and supplemented with the topnotch production crew in China. Those members contribute a lot in improving the products.
3. Creating the first-class pleated filter enterprise is our mutual goal for all staff in Lvyuan. Get quote! Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is committed to providing various types of pleated water filters to costumers both at home and abroad. Get quote! We keep mission in mind to create better pleated filter manufacturers with our professional spirit. Get quote!
