professional sintered filter cartridge rod for sea water desalination
1. Lvyuan sintered metal filter elements is made of high quality and durable raw materials which have been well selected before entering into the factory.
2. This product is somewhat fire retardant. The insulating materials used for this product meet higher demands in glow wire testing.
3. This product, with increasing technology and automation level, reduces the number of unskilled workers needed in the production process.
The stainless powder sintered filter is made by molding of stainless powder through high temperature sintering, also it adopts unique technology and strictly control production technique(include power grain distribution, molding and sintering).
The filter is characterized by high machinery strength, high conditions can be adjusted so as to produce the porous metal sintered filter with a wider precision scope. High-temperature resistance and Good air permeability.
Excellent machinery strength, applicable to the high temperature, high pressure and strong corrosivity.
◆◆ Main application cases
1. Filtration and recovery of catalyst.
2. Hot gas filtration in petrochemical industry
3. Purification of high temperature flue gas of metallurgy industry
4. Dust recovery of solid emulated bed and gas
5. Dust and end gas purification of thermal power and nuclear electric power generation.
Product Feature
◪ High-porosity and good air permeability, no media migration.
◪ High dirt holding capacity.
◪ High pressure resistance, withstand capacity and low pressure drop.
◪ High temperature resistance，Especially applicable to the hot gas filtration
◪ Various micron ratings available from 1 μm to 200 μm nominal.
◪ Strong corrosion resistant for wide chemical compatibility.
◪ Made entirely of SS316 or SS316L, cleanable and reusable
◪ Customized dimension are welcome.
Product Parameter
| Fiter Cartridge dimensions | |
| Length | 5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm) |
| Diameter | Ø60, 65, 70, 80 mm |
| Other dimensions | Customized by customer’s request. |
| Material of constructions | |
| Filter media | SUS316， 316L stainless steel |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, SOE, 215, 222, 226, M20, M30, M42, 1’’ NPT/BSP or as request. |
| Sealing material | Silicone, NBR, EPDM, Buna, Teflon, etc |
| Performance | |
| Removal rate | 0.2-200 μm, etc |
| Operation Temperature | ≥ -270ºC, ≤500ºC |
| Cleaning method | back flushing, ultrasonic or other non-abrasive cleaning |
| Maximum Operating Pressure differential | 4.0 bar |
Product Details
Product Applications
Company Features
1. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has been a qualified manufacturer both in the domestic and international market. We are proficient in manufacturing sintered filter cartridge .
2. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has sound quality assurance system, advanced detection equipment and strict quality management system.
3. Our company grows in every possible way and embraces the future. This adds to our services for customers bringing them the best of the industry. We aim to set up a diverse and inclusive workforce team and values individuals and their contribution. This allows us to better serve our customers. Our company is a great believer in giving back to the community, either fundraising for worthy causes close to our staff's hearts, donating furniture, or other items. Our firm bears societal responsibilities. The growth of new, more renewable substances combined with more effective resource usage has decreased the environmental impact appreciably.
