PTFE membrane pleated water filter cartridge with internal stainless steel reinforcing ring
Start Port:
Guangzhou
Production Capacity:
500 units/Month
Place of Origin:
Guangdong, China
Payment:
T/T, Western Union, MoneyGram, Alibaba Trade Assurance, paypal
MOQ:
10pcs
Model:
LY-PL-PTFE
Delivery Time:
Within 7 working days
Certification:
SGS, ISO 9001
Brand:
LVYUAN
Application Scope
cartridge housing manufacture produced by Lvyuan Water Purification Equipment is mainly used in the following fields.Lvyuan Water Purification Equipment always gives priority to customers and services. With a great focus on customers, we strive to meet their needs and provide optimal solutions.
Enterprise Strength
- Lvyuan Water Purification Equipment insists on the concept of 'survive by quality, develop by reputation' and the principle of 'customer first'. We are dedicated to providing quality and comprehensive services for customers.
1. The design of Lvyuan water purification equipment expresses attraction and deep expression to the customers.
2. water filter cartridge is a product which has many qualities and has a large assortment of applications it is suitable for.
3. The product is a superior quality, reliable, complete reverse osmosis drinking water purification system, which is intended for commercial applications.
4. Wearing this product can effectively prevent foot problems such as fungal nail infections, the pain of the feet and serious joint.
PTFE membrane cartridge filter is constructed of imported natural
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
Product Feature
◪ Excellent hydrophobic performance, the water erosion is more resistant than the common PVDF membrane.
◪ Withstand water shock, back pressure and repeated high temperature sterilization.
◪ 100% bacterial retention & effective filtration to 0.2 μm particle.
◪ 100% integrity tested.
◪ It is constructed of 2 kinds of hot welding materials(PTFE & PP), not any adhesives, clean & stable, meet the high standards of pharmaceutical industry.
Product Parameter
| Product Name | 10 inch PTFE membrane pleated filter cartridge with stainless steel 222 |
| Filter media | PTFE membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7‘’(69mm) |
| Length | 9.75'', 10'', 20'', 30'', 40'', Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.72m² |
| Max.operating temperature | 80℃, 0.173Mpa |
| Micron rating(μm) | 0.2, 0.45 |
Product Details
part.1
It is constructed of 2 kinds of hot welding materials(PTFE & PP), no any adhesives,
clean & stable.
part.2
DOE double opened PTFE membrane filter with PTFE gasket. It is a good choice for the pharmaceutical and ohter strict applications.
part.3
The adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution.
part.4
Different length & variety end cap are optional.
Product Applications
Reverse osmosis water system prefiltration
Electronic l industry
Filtration of mineral water
Filtration of organic solvent & ink
Filtration of pharmaceuticals
Filtration of biological
Company Features
1. As a trustworthy enterprise, Lvyuan has been offering professional one-stop solutions for customers for years.
2. Lvyuan places great emphasis on forward-looking technology applied in the manufacturing of water filter cartridge.
3. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. aims to help clients achieve their values and dreams. Call now! Lvyuan has always adhered to the principle of customer first. Call now! Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has accumulated a lot of OEM and ODM customization experience. Call now!
