pvdf pleated water filters with stainless steel for food and beverage

Start Port:

Guangzhou

Production Capacity:

400 units/Month

Place of Origin:

Guangdong, China

Payment:

T/T, Western Union, MoneyGram, Alibaba Trade Assurance, paypal

MOQ:

10pcs

Model:

LY-PL-PVDF

Delivery Time:

Within 7 working days

Certification:

SGS, ISO 9001

Brand:

OEM/Lvyuan

Inquiry

pvdf pleated water filters with stainless steel for food and beverage 11

The PVDF pleated filter cartridge is constructed of imported natural hydrophobic polyvinylenedifluoride(PVDF) membrane media and non-woven support materials. Adapters are thermally welded with media without using an glue, no any pollution. It is optimized for the clarification, prefiltration and sterile filtration of the liquids.High filtration micron, high flow rate, better hydrophobicity, sterilization at high temperature as well as chemical resistance. It is widely used in gas or liquid pre-filtration and widely used in final filtration.

Product Feature

◪ Universal chemical compatibility, especially for good oxidation resistance.
◪ Compatible with a wide range of solvents, acids and chemicals.
◪ Withstand high temperature stem sterilization or oxidizer sterilization.
◪ Better hydrophobicity, 100% bacterial retention and effective filtration of particles in gas filtration.
◪ No adhesives and droppings, clean and stable, suitable for pharmaceutical industry.

Product Parameter

Product Name	0.45 micron PVDF pleated membrane filter cartridge 10 inch (LY-PL-PVDF)
Filter media	PVDF membrane
Support	PP/Polypropylene
Core/End cap	PP/Polypropylene
Seal material	Silicone/EPDM/VITON/PTFE/NBR/TEFLON
Outer diameter	2.7”(69mm)
Length	9.75”, 10”, 20”, 30”, 40”, Customized
End cap	215/222/226/FIN/DOE/SS
Filtration area	≥0.72m²
Max.operating temperature	80℃, 0.173 Mpa
Micron rating(μm)	0.2, 0.45

Product Details

pvdf pleated water filters with stainless steel for food and beverage 12

part.1

100% filter cartridges were integrity tested assure the safe of filtration.

pvdf pleated water filters with stainless steel for food and beverage 13

part.2

PVDF membrane Microporous Folding water Filter is made of the pleated support layer consisting of imported polyvinylenedifluoride.

pvdf pleated water filters with stainless steel for food and beverage 14

part.3

Hydrophilic PVDF Membrane filter for liquids sterile filtration, absolute rating ≥99.99%.

pvdf pleated water filters with stainless steel for food and beverage 15

part.4

High throughput flow rate with minimal differential pressure.

Product Applications

pvdf pleated water filters with stainless steel for food and beverage 16

Serum, tissue culture media and media additives

pvdf pleated water filters with stainless steel for food and beverage 17

Diagnostics

pvdf pleated water filters with stainless steel for food and beverage 18

Filtration of wine

pvdf pleated water filters with stainless steel for food and beverage 19

Sterile filtration for organic solvents.

pvdf pleated water filters with stainless steel for food and beverage 20

Final sterile filtration of medicine liquid

pvdf pleated water filters with stainless steel for food and beverage 21

Filtration of biological

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
