10 inch 1 micron stainless steel SS316 metal porous sintered filter cartridge for liquid filtration
1. The design of the structure makes sintered metal filter very easy to operate. It can effectively control filtration precision
2. As per outer packing for sintered metal filter , Guangzhou Lvyuan Water Purification Equipment Co., Ltd. promises to put into high cost to keep it solid enough. It features a high flow rate and stable filtering accuracy
3. The product is of high quality. Because it has been tested for several times and its superior quality and can withstand the test of the time. All its elements are made with FDA compliant material for food and beverage contact
4. A number of quality tests will be carried out to ensure that products meet industry quality standards. It is designed with graded pores to help trap contaminants throughout the entire cross section for improved efficiency
5. Systematic quality control: it is the key control factors in the whole production process. From development to the shipment, the quality of this product is under the whole control of the quality team. It offers excellent filtration and good thermal stability
The stainless powder sintered filter is made by molding of stainless powder through high temperature sintering, also it adopts unique technology and strictly control production technique(include power grain distribution, molding and sintering).
The filter is characterized by high machinery strength, high conditions can be adjusted so as to produce the porous metal sintered filter with a wider precision scope. High-temperature resistance and Good air permeability.
Excellent machinery strength, applicable to the high temperature, high pressure and strong corrosivity.
◆◆ Main application cases
1. Filtration and recovery of catalyst.
2. Hot gas filtration in petrochemical industry
3. Purification of high temperature flue gas of metallurgy industry
4. Dust recovery of solid emulated bed and gas
5. Dust and end gas purification of thermal power and nuclear electric power generation.
Product Feature
◪ High-porosity and good air permeability, no media migration.
◪ High dirt holding capacity.
◪ High pressure resistance, withstand capacity and low pressure drop.
◪ High temperature resistance，Especially applicable to the hot gas filtration
◪ Various micron ratings available from 1 μm to 200 μm nominal.
◪ Strong corrosion resistant for wide chemical compatibility.
◪ Made entirely of SS316 or SS316L, cleanable and reusable
◪ Customized dimension are welcome.
Product Parameter
| Fiter Cartridge dimensions | |
| Length | 5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm) |
| Diameter | Ø60, 65, 70, 80 mm |
| Other dimensions | Customized by customer’s request. |
| Material of constructions | |
| Filter media | SUS316， 316L stainless steel |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, SOE, 215, 222, 226, M20, M30, M42, 1’’ NPT/BSP or as request. |
| Sealing material | Silicone, NBR, EPDM, Buna, Teflon, etc |
| Performance | |
| Removal rate | 0.2-200 μm, etc |
| Operation Temperature | ≥ -270ºC, ≤500ºC |
| Cleaning method | back flushing, ultrasonic or other non-abrasive cleaning |
| Maximum Operating Pressure differential | 4.0 bar |
Product Details
Product Applications
Company Features
1. Supported by high quality sintered metal filter , Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is greatly trusted by customers.
2. Relying on the advantages of technological innovation, it actively contributes to the popularity of sintered stainless steel filter .
3. We make sure that all our orders meet the highest standards and are delivered on time. This dedication has helped us maintain our reputation of delivering quality products within due time. No matter how big or small the project, we have always upheld our promise to customers. Welcome to visit our factory!
