Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.


Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 1
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 1

Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water

Inquiry

Overview
Quick Details
Condition:
New
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
After Warranty Service:
Online support
Local Service Location:
none
Showroom Location:
none
Place of Origin:
Guangdong, China
Brand Name:
Lvyuan / OEM
Material:
carton, PP / PTFE / PES / Nylon 6 / PVDF
Weight:
depends
Size:
depends
Power:
0
Warranty:
Unavailable
Product name:
pes water filter cartridge
Micron Rate:
0.1 to 60 micron pleated filter cartridge
Length:
5", 10", 20", 30", 40" inch
Filter Media:
pleated membrane
End Cap:
DOE,222+Fin,222+Flat,226+Fin,226+Flat
Gasket/O ring material:
Silicon/EPDM/NBR/Viton/Tflon
Usage:
liquid filter elements, water filter parts
Inner core:
PP / stainless steel
Supply Ability
Supply Ability:
5000 Piece/Pieces per Day 2.5 inch filter cartridge
Product Description
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 2
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 4
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 6

40 30 20 10 5 2.5 inch Water Filtration PP PES PTFE pleated filter cartridge for Wine, Beer, Bottled Water Processing

The PP pleated filter cartridge uses pleated polypropylene fiber membrane as filtration media.

The PP Polypropylene cartridge is an advanced fixed intensive filter and available in a wide range of retention rating from 0.1μm to 60μm. The pore size is not affected by the vibration of feeding pressure. Due to its unique low differential pressure, high flow volume, excellent filtration capability attracted many customers.

Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 8
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 10
Detail of Pleated filter cartridge
Jumbo / High flow rate Pleated Filter Cartridge
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 12
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 14
End Cap for pleated filter cartridge
7 Round 30 inch Stainless Steel cartridge filter housing
Application
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 16

1. Electronic industry: RO reverse osmosis water system prefiltration, deionized water system prefiltration.
2. Food industry: filtration of beverage, beer and mineral water.
3. Chemical industry: filtration of organic solvent and ink.
4. Pharmaceutical industry: filtration of pharmaceuticals, biologicals, serum products, compressed air and gas.
5. Others: filtration of plating solution, process fluids, photoresist and magnetic media

Specification
Filter Media Option
PTFE filter cartridge
Nylon 6 filter cartridge
PES filter cartridge
PVDF filter cartridge
Length
5, 10, 20, 30, 40
5, 10, 20, 30, 40
5, 10, 20, 30, 40
5, 10, 20, 30, 40
5, 10, 20, 30, 40"
Micron Rate
0.1, 0.2, 0.45, 0.65, 0.8, 1, 2, 3, 5, 10, 20, 25, 30, 50, 60 micron
0.2, 0.45 micron
0.2, 0.45, 0.65, 1 micron
0.1, 0.2, 0.45, 0.65 micron
0.2, 0.45 micron
End Cap
DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat
DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat
DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat
DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat
DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat
Inner Diameter
28mm
28mm
28mm
28mm
28mm
Outer Diameter
68mm (can be customized)
68mm (can be customized)
68mm (can be customized)
68mm (can be customized)
68mm (can be customized)
Jumbo Size
ID: 30mm, OD: 110~115mm
ID: 30mm, OD: 110~115mm
ID: 30mm, OD: 110~115mm
ID: 30mm, OD: 110~115mm
ID: 30mm, OD: 110~115mm
Gasket/O ring material
Silicon/EPDM/NBR/Viton/Teflon
Silicon/EPDM/NBR/Viton/Teflon
Silicon/EPDM/NBR/Viton/Teflon
Silicon/EPDM/NBR/Viton/Teflon
Silicon/EPDM/NBR/Viton/Teflon
Effective filtration area
0.4-0.7m²
≥0.72m²
≥0.6m²
≥5m²
≥0.72m²
Max.working pressure difference
0.42Mpa at 25℃
0.42Mpa at 25℃
0.42Mpa at 25℃
0.42Mpa at 25℃
0.42Mpa at 25℃
Max.back pressure
0.28Mpa at 60℃
0.35Mpa at 60℃
0.35Mpa at 25℃
0.21Mpa at 25℃
0.21Mpa at 25℃
Max. working temperature
88℃ at 0.28Mpa, 60℃ at 0.42Mpa
142℃ at 0.276Mpa
49℃ at 0.21Mpa
140℃ at 0.28Mpa
80℃ at 0.173Mpa
Sterilizing temperature
121℃, 30mins
121℃, 30mins
121℃, 30mins
121℃, 30mins
121℃, 30mins
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 18
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 20
Related Products
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 22
Our Company

Guangzhou Lvyuan Water Purification Equipment Co.,Ltd is a comprehensive enterprise. As a Leader Manufacturer in Guangzhou city, our competitive product lines including:
1. All kinds of Filter Cartridges, Pleated / Melt Blown / Sintered etc.
2. Cartridge filter housings and bag filter housings
3. RO, UF, MBR water purifier and equipment
4. Water treatment equipments
5. Many kinds of Water purifiers and equipments, water softners, and more.
We devote to filtration development for more than 10 years. We can supply advanced technical support and solution for all of our customers during and after warranty period.

Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 24
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 26
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 28
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 30
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 32
Packing & Delivery
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 34
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 36
Lvyuan Filter Good Selling stainless steel pleated filter cartridge made in china for water 38
FAQ

1. Q: Are you factory?
A: Yes, we are the professional manufacturer with continuous and improved R & A production, sales and service supply. We will always provide the best technical service support to our clients both in and after warranty period.
2. Q: How to get a quotation?
A: In order to send you our best price, please kindly inform us detail product parameters and order quantity.
3. Q: Can I get your products with our logo and design?
A: Customized service is available. We can OEM or ODM with your logo.
4. Q: What's the MOQ ?
A: We can offer the quantity you required, as we don't dictate MOQ terms.
