Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
cartridge filters ss filtration Lvyuan Brand
- Lvyuan Water Purification Equipment extensively takes excellent talents in, so as to establish a management team with a good education background, high quality, and high efficiency. The team members are committed to leading the company to develop rapidly by adopting modern management concept.
- Lvyuan Water Purification Equipment always stands on customer's side. We do everything we can to meet customers' needs. We are committed to providing quality products and caring services.
- Lvyuan Water Purification Equipment will adhere to the enterprise spirit which is to be people-oriented, sincere and trustworthy. We follow the business concept of 'talent is the foundation, sci-tech is the guide, management is the basis, quality is the center'. With a focus on the development tendency of domestic and foreign markets, we strive to achieve product differentiation depending on technological innovation. Our goal is to continuously provide more quality products and services for consumers.
- Lvyuan Water Purification Equipment was founded in 2009. Over the years, we strive to learn foreign and domestic advanced manufacturing experience and continuously improve production technology. We improve the corporate governance system and pursue excellence in development. We establish a good corporate image in the industry.
- Lvyuan Water Purification Equipment now has a sales network covering the major cities in the country. We also construct a preliminary sales network in some second and third tier cities
1. Lvyuan is manufactured by our experienced workers who use optimum raw materials. It does not secrete dissoluble material during operation
2. has many functions, such as . There is different porosity across the depth of its filter medium
3. The quality of can be guaranteed with the implement ion of strict quality test. It is available in a wide selection of micron ratings from 1 to 100 μm
Product Feature
◪ Uniform structure, narrow pore size distribution, and high separation efficiency;
◪ High porosity, the resistance of filtration less, and the penetration efficiency is high;
◪ High temperature resistant, it can be normally used below in 280 degree;
◪ Good chemical stability, acid & alkali corrosion resistance, and oxidation resistance;
◪ No particles fall off, it will not make the concentrate form secondary pollution, it conforms to be food hygiene and pharmaceutical GMP requirements;
◪ Good mechanical performance, it can have the suction filtration and press-filtration, simple operation;
◪ Low differential pressure, the area of cover is small, and large water flow rate;od mechanical performance, it can have the suction filtration and press-filtration, simple operation;
◪ Strong antimicrobial ability, no microbes.
◪ The finished-products technology is good, the overlength of overall length can be reached to 1000mm.
◪ It can be on-line regeneration, easy to clean, and long service life.
Product Parameter
| Fiter Cartridge dimensions | |
| Length | 5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm |
| Diameter | Ø22, 30, 50, 60, 70, 80, 100, 120mm |
| Other dimensions | Customized by customer’s request. |
| Material of constructions | |
| Filter media | Titanium |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, 215, 222, 226, M20, M30, M42 or as request. |
| Sealing material | Silicone, NBR, EPDM, Fluoro rubber, etc |
| Performance | |
| Removal rate | 0.1, 0.45, 1, 3, 5, 10,20, 30, 40, 50, 100um |
| Porosity | 28-50% |
| Temperature Tolerance | ≦300℃ wet |
| Permeability | 0.02-20L/cm2 min Pa |
| Maximum Operating Pressure differential | 6.0bar |
| Flow rate (L/H) | 180, 200, 250, 280, 300, 350, 500, 800, 1000, 1500, 1600 |
◆◆Pure water flow rate reference table: the initial value of 10'' sintered titanium cartridge (P=0.2 MPa, 1cP, 25℃)
| Micron rate (μm) | 0.2 | 0.45 | 1 | 2 | 3 | 5 | 10 | 20 | 30 |
| Flow rate (L/H) | 180 | 200 | 250 | 280 | 300 | 350 | 500 | 800 | 1000 |
Product Details
Product Applications
Company Features
1. Lvyuan from Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is a very famous brand at home and abroad.
2. There is a full set of quality testing system to ensure quality of .
3. Our ambition is to become the leading manufacturer. Welcome to visit our factory!
