Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 1

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 2

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 3

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17

Inquiry

Overview

Quick Details

Place of Origin:: China

Brand Name:: Lvyuan/OEM

Model Number:: LY-PLF-01

Power (W):: 0

Voltage (V):: 0

After-sales Service Provided:: none

Warranty:: none

Type:: Reverse Osmosis

Certification:: GS

Use:: Household Pre-Filtration

Application:: Car, RV, Outdoor, Hotel, Garage, Commercial, Household

Power Source:: Manual

Name:: industrial filter element

Filter membrane material:: PP/PVDF/PTFE/PES/Nylon

Length:: 5 / 10 / 20 / 30 / 40 / 50 / 60 inch

Conector:: Fin/222/226/215/DOE/Thread

Micron:: 0.22/0.5/1/3/5/10/25/50/75/100/150

Sealing method:: Hot melting welding

Diameter:: 70mm/OEM

Inner Core:: PP/SS/OEM

MOQ:: Currently no limited

Supply Ability

Supply Ability:: 5000 Piece/Pieces per Week

Promotional Good Quality industrial filter element Various sizes For Food & Beverage Factory

Product Description

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 4

Product Name	Water treatment plant RO pleated filter 5 microns PP cartridge water filter with 10 20 30 40 inch length
Filtration media	PP/PTFE/PES/PVDF/Nylon
Support material	Polypropylene
Core & Structural components	Polypropylene
Inner core	PP/Stainless steel
Packing method	Polybag/Vacuum
Filtration precision	0.1μm, 0.2μm, 0.45μm, 0.65μm,0.8μm,1μm,2μm,3μm,5μm,10μm,20μm,25μm,30μm,50μm
Length	2.5", 5". 10", 20", 30", 40", 50", 60", OEM
Adaptor	215/222/226/Fin/Flat/Thread/OEM
Sealing method	Hot melting welding
Sealing gasket & O-ring material	Silicone rubber; Nitrile butadiene rubber, EPDM, Fluorine rubber.
Effect filtration area	≥0.6m²
Filter cartridge diameter	69mm
Max. working temperature	PP: 88℃,0.27Mpa； PTFE: 80℃, 0.173Mpa ；PES: 85℃, 0.28Mpa PVDF: 80℃, 0.173Mpa；Nylon: 49℃, 0.21Mpa
Max. positive differential pressure	0.42Mpa (25℃)
Max. back pressure differential pressure	0.28Mpa (25℃)
Sterilization conditions	121℃ 30min
Applications	Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 6

PP melt blown water filter cartridge

Polypropylene melt blown filter cartridge or PP spun water filter, PP filter, PP filter cartridge is the most widely used filtration consumable products in domestic and industrial water treatment systems.

PP melt blown filter cartridges (PPF) are made of 100% pure polypropylene fiber, providing broad wide chemical compatibility.
Melt Blown sediment filter cartridge has strong pollutants holding capacity.

Polypropylene microporous membrane filter

PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications. They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of
feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns. The high surface area ensures long service life and low initial pressure drops.

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 8

Detailed Images

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 10

Groove surface PP sediment filter cartridges.

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 12

Flat surface PP sediment filter cartridge

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 14

215 222 226 Flat/Fin end cap PP filter, code 0 3 6 7 8 9 available.

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 16

DOE opened pleated filter

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 18

OEM customized size filter

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 20

Different end caps pleated filter

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 22

PP melt blown filter cartridge with 1 2 3 layers for option

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 24

PP shell Polypropylene melt blown filter cartridge

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 26

Customize PP core or stainless steel shell/core pp filter cartridge

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 28

Application

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 30

RO WATER TREATMENT

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 32

BOTTLED MINERAL WATER

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 34

CHEMICAL TECHNOLOGY FILTRATION

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 36

BEER & BEVERAGE FILTRATION

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 38

PETROCHMICAL INDUSTRY

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 40

SEA DESALINATION WATER EQUIPMENT

Packing & Delivery

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 42

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 44

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 46

Container for shipment

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 48

Container for shipment

Certifications

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 50

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 52

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 54

Our Company

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 56

Lvyuan titanium stainless steel filter housing manufacturers with fin end cap for sea water desalination17 58

Let's Make Custom Water Filter Cartridge For You Now.

Guangzhou Lvyuan Water Purification Equipment Co., Ltd. provides complete, efficient and compact services. It can effectively control filtration precision. water filter cartridges products from Guangzhou Lvyuan Water Purification Equipment Co., Ltd. cover many countries and regions in the world. It can effectively control filtration precision.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
