Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
Lvyuan best high flow pleated filter cartridge manufacturer for industry
1. high flow pleated filter cartridge's design idea is based on the search for a high-quality life standard. It is available in a wide selection of micron ratings from 1 to 100 μm
2. This product would benefit business owners a lot. It allows the production projects to be finished in a short time, which reduces the waste of time. It is manufactured from 100% Polypropylene construction
3. The product features a clean appearance. It is coated with a special layer to effectively prevent adhesion of dust or oil smoke when being placed. Being thermally welded, its caps are not prone to crack or fall off
Product Feature
◪ All contaminants can be removed within the cartridges because of the flow direction.
◪ Up to 110m³/h flow rate per one filter cartridge for water filtration.
◪ Max. 50% reduction of the filter system.
◪ Multi membrane layers for large dirt holding in the high flow filter elements.
◪ Thermally bonded construction for stronger pressure resistance.
◪ Handle design quick installation, safety and reduce the cost.
Product Parameter
| Product Name | Repalcement High flow water filter cartridge 60 inch (LY-HFPL) |
| Filter media | PP/Polypropylene membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR |
| Outer diameter | 6”(152mm) |
| Inner diameter | 3.5 inch(89mm) |
| Length | 20”, 40”, 60”, Customized |
| Max.operating temperature | 82℃ |
| Micron rating(μm) | 1, 4, 5, 10, 15, 20, 40, 70, 100 |
Product Details
★ Graded filtration pore sizes in one high flow element.
★ Easier and more convinient installation and replaced.
★ Pleated with optimized membrane structure, better filtration and efficiency.
★ U-shaped sealing groove ensures high filtration efficiency.
★ From filter inside to outside filtration, all impurities are trapped inside the filter.
Product Applications
Municipal tap water, Prefiltration of RO, Pre treatment of sea water desalination
Company Features
1. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is a trusted Chinese manufacturer. We have the knowledge, experience, and passion to create perfect high flow water filter system . Our production capacity occupies steadily in the forefront of the high flow pleated filter cartridge industry.
2. We've been focusing on manufacturing high quality high flow filters for domestic and abroad customers.
3. The quality of our high flow water filter replacement cartridge still keeps unsurpassed in China. We work towards achieving cost savings at various stages such as purchasing raw materials, shortening lead time, and reducing manufacturing expenses through waste reduction. Get info!
