Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
Lvyuan sintered filter suppliers rod for sea water desalination
1. Lvyuan sintered metal filter cartridge is offered utilizing the advanced technology and high-efficiency equipment. It has found a variety of applications ranging from industrial, chemical process, food and beverage, cosmetics and water
2. This product will increase productivity, division of labor and systematization, which will bring profit to the producers. Being thermally welded, its caps are not prone to crack or fall off
3. All the sintered filter suppliers are reliable in property and reputably appraised by customers. It is resistant to putridity, acid and alkali, organic or inorganic solvent
4. sintered filter suppliers is applied with high quality materials in high grade. It can provide accurate analysis and results for sensitive ion chromatography applications
5. Every defect of the product has been quickly detected and timely corrected, ensuring the consistent quality. It will trap larger particles in the outer layers and capture smaller particles in the deep layer
Product Feature
◪ Uniform structure, narrow pore size distribution, and high separation efficiency.
◪ High porosity, the resistance of filtration less, and the penetration efficiency is high.
◪ High temperature resistant, it can be normally used below in 280 degree.
◪ Good chemical stability, acid & alkali corrosion resistance, and oxidation resistance.
◪ Good mechanical performance, it can have the suction filtration and press-filtration, simple operation.
◪ Low differential pressure, the area of cover is small, and large water flow rate;od mechanical performance, it can have the suction filtration and press-filtration, simple operation.
◪ Strong antimicrobial ability, no microbes.
◪ The finished-products technology is good, the overlength of overall length can be reached to 1000mm.
◪ It can be on-line regeneration, easy to clean, and long service life.
◪ No particles fall off, it will not make the concentrate form secondary pollution, it conforms to be food hygiene and pharmaceutical GMP requirements.
Product Parameter
| Fiter Cartridge dimensions | |
| Length | 5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm） |
| Diameter | Ø22, 30, 50, 60, 70, 80, 100, 120mm |
| Other dimensions | Customized by customer’s request. |
| Material of constructions | |
| Filter media | Titanium |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, 215, 222, 226, M20, M30, M42 or as request. |
| Sealing material | Silicone, NBR, EPDM, Fluoro rubber, etc |
| Performance | |
| Removal rate | 0.1, 0.45, 1, 3, 5, 10,20, 30, 40, 50, 100um |
| Porosity | 28-50% |
| Temperature Tolerance | ≦ 300℃ wet |
| Permeability | 0.02-20L/cm2 min Pa |
| Maximum Operating Pressure differential | 6.0 bar |
| Flow rate (L/H) | 180, 200, 250, 280, 300, 350, 500, 800, 1000, 1500, 1600 |
◆◆Pure water flow rate reference table: the initial value of 10'' sintered titanium cartridge (P=0.2 MPa, 1cP, 25℃)
| Micron rate (μm) | 0.2 | 0.45 | 1 | 2 | 3 | 5 | 10 | 20 | 30 |
| Flow rate (L/H) | 180 | 200 | 250 | 280 | 300 | 350 | 500 | 800 | 1000 |
Product Details
Product Applications
Company Features
1. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. specializes in providing high quality sintered filter suppliers . We had successfully completed many big product projects with cooperations around the world. And now, these products have been widely sold around the globe.
2. Our company has introduced a team of professional technicians who are well-equipped with expertise and experience. The fact proves that they have helped our company accomplish technological innovation.
3. We have established a substantial position in the neighboring markets profiting from the opportunities available. We are going global by exporting more products to the main countries such as the US, Japan, Russia, etc. Lvyuan always sticks to the client first principle. Inquire now!
