Pleated Filter Cartridge Suppliers LY-PL-PTFE by Lvyuan Filter
Product details of the pleated filter cartridge suppliers
Product Introduction
The raw material of Lvyuan Filter pleated filter cartridge suppliers goes through a rigorous selection procedure. The product is reliable in high quality and performance. Lvyuan Filter ensures each step of producing pleated filter cartridge suppliers under the strict quality assurance.
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. Adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
Product Feature
◪ Excellent hydrophobic performance, the water erosion is more resistant than the common PVDF membrane.
◪ Withstand water shock, back pressure and repeated high temperature sterilization.
◪ 100% bacterial retention & effective filtration to 0.2 μm particle.
◪ 100% integrity tested.
◪ It is constructed of 2 kinds of hot welding materials(PTFE & PP), not any adhesives, clean & stable, meet the high standards of pharmaceutical industry.
Product Parameter
| Product Name | 10 inch PTFE membrane pleated filter cartridge with stainless steel 222 |
| Filter media | PTFE membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7‘’(69mm) |
| Length | 9.75'', 10'', 20'', 30'', 40'', Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.72m² |
| Max.operating temperature | 80℃, 0.173Mpa |
| Micron rating(μm) | 0.2, 0.45 |
Product Details
Product Applications
Reverse osmosis water system prefiltration
Company Feature
• Compact in structure, stable in performance, reliable in quality, high in cost performance and wide in application, Lvyuan Water Purification Equipment 's mechanical equipment greatly improves production efficiency.
• Lvyuan Water Purification Equipment has always been dedicated to providing customers with good products and sound after-sales service.
• Lvyuan Water Purification Equipment has a professional R&D team and a high-quality production team, who are the solid foundation of corporate development. The team members are experienced and innovative, for they are engaged in production for many years.
• Lvyuan Water Purification Equipment is located at the intersection of different highways with great geographic position and easy traffic. Based on that, the distribution of supply is convenient and it is the ideal place for the sustainable development of the enterprise.
• Strong in production capability and perfect in governance mode, Lvyuan Water Purification Equipment is able to provide quality products and custom services.
Lvyuan Water Purification Equipment has more discounts for large-quantity orders. Feel free to consult us!
