Sintered Carbon Filter Cartridge Upplier

Product details of the sintered carbon filter cartridge

Product Overview

sintered carbon filter cartridge is made with well-chosen materials and exquisite workmanship. It is of excellent performance and reliable quality. It is safe and stable when running and 24-hour continuous running is available. Lvyuan Filter sintered carbon filter cartridge is made from high quality materials, which are sourced from reliable suppliers. The product is in compliance with international industry quality standards. sintered carbon filter cartridge is widely used in the industrial production, including cutting and deep processing of various metal tubes. More and more customers think highly of its application value.

Product Description

We insist on regulating the production process of the products in accordance with standards, so as to promote the sintered carbon filter cartridge has higher quality. Compared with peer products, the specific advantages are mainly reflected in the following aspects.

Overview

Quick Details

Applicable Industries:

Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Home Use, Printing Shops, Construction works , Food & Beverage Shops, Advertising Company

After Warranty Service:

Online support

Local Service Location:

none

Showroom Location:

none

Video outgoing-inspection:

Provided

Machinery Test Report:

Provided

Marketing Type:

Ordinary Product

Warranty of core components:

1 Year

Core Components:

Pressure vessel

Place of Origin:

Guangdong, China

Brand Name:

Lvyuan/OEM

Warranty:

1 Year

After-sales Service Provided:

Online support

Product name:

acf filter cartridge

Size:

Customized

Micron Rate:

1, 3, 5, 10, 20, 50, 100um

Material:

activated carbon, coconut shell

Length:

OEM, 5", 10", 20", 30", 40"

Outer diameter:

OEM, 50, 60, 70, 80mm

End cap:

DOE,SOE,222,226,215, M36, M24, M22, M20 thread interface

Certification:

ISO9001

Usage:

Air or Water Purification

Working pressure:

0.1 to 30Mpa

Supply Ability

Supply Ability:

5000 Piece/Pieces per Day carbon fiber water filter

Online Customization

10 20 inch Slim Jumbo ACF Activated Carbon Fiber Cartridge for Water Purifier Filtration

Product Description

10 20 inch Slim Jumbo ACF Activated Carbon Fiber Filter Cartridge for Water Purifier Filtration

LVYUAN can custom-make industry-standard sized sintered carbon blocks Filter Element to suit the requirements of OEMs worldwide.

LVYUAN activated carbon fiber filter cartridge is combined with the performance of depth filtration with the absorption of activated carbon fine. More than 80% of the carbon atoms of the carbon fiber filter are locatedd on the inner and outer surfaces, and they form a unique adsorption structure, which is called a surface solid. The outside deep filter media can remove particles while the activated carbon held within the filter cloth absorb the smell, odor, sediment, pigment, VOC, and organic chemicals. The inside fiber filter prevents carbon particles and fine pollutants form passing through, thus increasing an efficient quality and integrated filtration.

Specification

Name	Activated Carbon Fiber Filter Cartridge
Filter Media	Activated carbon, (other anti-scale, heavy metal removal material available for option.)
Material	Coconut shell, Coal carbo
Iodine value	600 to 1500 available
Filtration rate	1um, 3um, 5um, 10um, 20um, 30um, 50um, 80um, 100um, 120um.
Dimension	can be custom-made according to customer's requirement
Length	5, 10, 20, 30, 40 inch, OEM
Outer diameter	50, 60, 70, 80mm, OEM
End cap	DOE, M20, M30,M36, M42, 215, 222, 226, OEM
Gasket/Oring material	Silicone, EPDM, NBR, Viton etc
Netting material	Polypropylene
Operating temperature	≤60ºC
Maximum operating pressure	10 bar

Features

1. High dirt holding capacity, longer service life.

2. Filtration & adsorption integrated.

3. Strong adsorption capacity, longer service life.

4. Fits to all the standard filter housings.

5. Chlorine, color, odor, organic matter removal.

Application

1. RO water pre-treatment in municipal tap water.

2. Pre filtration for drinking water filter

3. Solution to remove oil and aromatic.

4. Removing dissociative chlorine and volatile organics compounds (VOS) in solution.

5. Industry water, plating filtration.

6. Food and Beverage.

7. Remove smell, odor, color and organic pigment.

8. Organic chemical removal.
