Sintered Filter Suppliers ISO 9001 - - Lvyuan Filter-1
Product details of the sintered filter suppliers
Quick Detail
sintered filter suppliers is manufactured based on good materials and traditional techniques as well as modern technology. It has advantages such as reliable performance, good quality, high working efficiency, and long service life. Lvyuan Filter sintered filter suppliers has a revolutionary and innovative design. This product meets or exceeds all quality and safety standards. sintered filter suppliers is widely applicable to the food industry. It can fulfill the manufacturing needs of various types of food, such as production, processing, and packaging. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. can produce samples according to the design drawings and samples provided by customers.
Product Description
Next, the details of sintered filter suppliers are shown for you.
Product Feature
◪ Uniform structure, narrow pore size distribution, and high separation efficiency.
◪ High porosity, the resistance of filtration less, and the penetration efficiency is high.
◪ High temperature resistant, it can be normally used below in 280 degree.
◪ Good chemical stability, acid & alkali corrosion resistance, and oxidation resistance.
◪ Good mechanical performance, it can have the suction filtration and press-filtration, simple operation.
◪ Low differential pressure, the area of cover is small, and large water flow rate;od mechanical performance, it can have the suction filtration and press-filtration, simple operation.
◪ Strong antimicrobial ability, no microbes.
◪ The finished-products technology is good, the overlength of overall length can be reached to 1000mm.
◪ It can be on-line regeneration, easy to clean, and long service life.
◪ No particles fall off, it will not make the concentrate form secondary pollution, it conforms to be food hygiene and pharmaceutical GMP requirements.
Product Parameter
| Fiter Cartridge dimensions | |
| Length | 5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm） |
| Diameter | Ø22, 30, 50, 60, 70, 80, 100, 120mm |
| Other dimensions | Customized by customer’s request. |
| Material of constructions | |
| Filter media | Titanium |
| Connector type | Flat, Insert type, Thread type, Fin |
| End caps | DOE, 215, 222, 226, M20, M30, M42 or as request. |
| Sealing material | Silicone, NBR, EPDM, Fluoro rubber, etc |
| Performance | |
| Removal rate | 0.1, 0.45, 1, 3, 5, 10,20, 30, 40, 50, 100um |
| Porosity | 28-50% |
| Temperature Tolerance | ≦ 300℃ wet |
| Permeability | 0.02-20L/cm2 min Pa |
| Maximum Operating Pressure differential | 6.0 bar |
| Flow rate (L/H) | 180, 200, 250, 280, 300, 350, 500, 800, 1000, 1500, 1600 |
◆◆Pure water flow rate reference table: the initial value of 10'' sintered titanium cartridge (P=0.2 MPa, 1cP, 25℃)
| Micron rate (μm) | 0.2 | 0.45 | 1 | 2 | 3 | 5 | 10 | 20 | 30 |
| Flow rate (L/H) | 180 | 200 | 250 | 280 | 300 | 350 | 500 | 800 | 1000 |
Product Details
Product Applications
Company Introduction
Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is thought of an expert in producing sintered filter suppliers. We also provide a series of related product portfolio. We have an experienced marketing team who forms their own complete marketing system. They are quite familiar with market trends and clients' purchasing tendency. This enables them to master clients' actual demands. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. intends to be among the very influential high-end brands in producing sintered filter suppliers. Inquiry!
Lvyuan Water Purification Equipment 's water filter cartridges,cartridge filter manufacturer,cartridge housing manufacture have reasonable price and guaranteed quality. If you have any needs, please contact us as soon as possible!
