Water Filtration Cartridges Made in China

Product details of the water filtration cartridges

Quick Detail

water filtration cartridges is made of extra-thick stainless steel and manufactured based on advanced production technology. It is a popular product in the market with advantages such as firmness, durability, safety, environmental protection, and low energy consumption. Confirmed design: the design of Lvyuan Filter water filtration cartridges has been confirmed by users, which combines both functionality and aesthetics and is carried out by a team of talents. Timely corrective measures have been taken when spotting defects, ensuring the consistently high quality of the product. water filtration cartridges is commonly used in many industries including food and beverage, pharmaceutical, daily necessities, hotel supplies, metal materials, agriculture, chemicals, electronics, and machinery. With the help of water filtration cartridges, Lvyuan Filter is a reliable company to many customers.

Product Description

The specific details of water filtration cartridges are presented below.

Overview

Quick Details

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company

After Warranty Service:

Online support

Local Service Location:

none

Showroom Location:

none

Video outgoing-inspection:

Provided

Machinery Test Report:

Provided

Marketing Type:

Ordinary Product

Warranty of core components:

1 Year

Core Components:

Gearbox, Pressure vessel, Pump, Gear, Bearing, Engine, Motor, PLC

Place of Origin:

Guangdong, China

Brand Name:

OEM/Lvyuan

Material:

PP/PE

Weight:

0.5

Size:

Customized

Power:

0

Warranty:

3 months

After-sales Service Provided:

Online support

Name:

mini pleat filter

Filter membrane material:

PP/PVDF/PTFE/PES/Nylon

Length:

5 / 10 / 20 / 30 / 40 / 50 / 60 inch

Conector:

Fin/222/226/215/DOE/Thread

Micron:

0.22/0.5/1/3/5/10/25/50/75/100/150

Sealing method:

Hot melting welding

Diameter:

70mm/OEM

Inner Core:

PP/SS/OEM

MOQ:

Currently no limited

Supply Ability

Supply Ability:

5000 Piece/Pieces per Week

Online Customization

High Efficiency mini pleat filter For Printing Shops

Product Description

Product Name	Water treatment plant RO pleated filter 5 microns PP cartridge water filter with 10 20 30 40 inch length
Filtration media	PP/PTFE/PES/PVDF/Nylon
Support material	Polypropylene
Core & Structural components	Polypropylene
Inner core	PP/Stainless steel
Packing method	Polybag/Vacuum
Filtration precision	0.1μm, 0.2μm, 0.45μm,  0.65μm,0.8μm,1μm,2μm,3μm,5μm,10μm,20μm,25μm,30μm,50μm
Length	2.5", 5". 10", 20", 30", 40", 50", 60", OEM
Adaptor	215/222/226/Fin/Flat/Thread/OEM
Sealing method	Hot melting welding
Sealing gasket & O-ring material	Silicone rubber; Nitrile butadiene rubber, EPDM, Fluorine rubber.
Effect filtration area	≥0.6m²
Filter cartridge diameter	69mm
Max. working temperature	PP: 88℃,0.27Mpa； PTFE: 80℃, 0.173Mpa ；PES: 85℃, 0.28Mpa PVDF: 80℃, 0.173Mpa；Nylon: 49℃, 0.21Mpa
Max. positive differential pressure	0.42Mpa (25℃)
Max. back pressure differential pressure	0.28Mpa (25℃)
Sterilization conditions	121℃ 30min
Applications	Chemical industry; Organic solvents; Various of alcohols; Chemical reagents filtration; Sterile tank breathing apparatus; Pharmaceutical industry; Food industry; Electronic industry; RO water treatment; Medical liquid filtration;

PP melt blown water filter cartridge

Polypropylene melt blown filter cartridge or PP spun water filter, PP filter, PP filter cartridge is the most widely used filtration consumable products in domestic and industrial water treatment systems.

PP melt blown filter cartridges (PPF) are made of 100% pure polypropylene fiber, providing broad wide chemical compatibility. Melt Blown sediment filter cartridge has strong pollutants holding capacity.

Polypropylene microporous membrane filter

PP pleated filter cartridge deliver high efficiency and consistent filtration of fluids in a wide range of critical applications. They are constructed of pleated membrane filter media that provides removal of particles from 0.1 to 60um, the pore size is not affected by the vibration of feeding pressure, due to its unique low differential pressure, high flow volume, excellent filtration microns. The high surface area ensures long service life and low initial pressure drops.

Detailed Images

Groove surface PP sediment filter cartridges.

Flat surface PP sediment filter cartridge

215 222 226 Flat/Fin end cap PP filter, code 0 3 6 7 8 9 available.

DOE opened pleated filter

OEM customized size filter

Different end caps pleated filter

PP melt blown filter cartridge with 1 2 3 layers for option

PP shell Polypropylene melt blown filter cartridge

Customize PP core or stainless steel shell/core pp filter cartridge

Application

RO WATER TREATMENT

BOTTLED MINERAL WATER

CHEMICAL TECHNOLOGY  FILTRATION

BEER & BEVERAGE FILTRATION

PETROCHMICAL INDUSTRY

SEA DESALINATION WATER EQUIPMENT

Packing & Delivery

Container for shipment

Container for shipment

Certifications

Our Company

Let's Make Custom Water Filter Cartridge For You Now.

.

Company Information

Since the establishment, Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has been engaged in the production of water filtration cartridges. We have quickly expanded our operations globally. To make it healthier, our water filtration cartridges applies not only the most advanced technology but also adopts the raw materials. We are committed to acting in an environmentally responsible way using best practice and best available materials in all our activities. Get info!
Lvyuan Water Purification Equipment 's water filter cartridges,cartridge filter manufacturer,cartridge housing manufacture are high-quality and priced-reasonably. If you want to know more relevant information, please contact us directly!
