sintered metal filter liquid Lvyuan

Start Port:
Guangzhou
Place of Origin:
Guangdong, China
Payment:
T/T, Alibaba Trade Assurance, paypal
MOQ:
10pcs
Model:
LY-TIC
Delivery Time:
In 7 to 15 working days
Certification:
SGS, ISO 9001
Brand:
LVYUAN
Inquiry
Company Advantages
1. The quality Lvyuan sintered metal filter cartridge is produced with excellent workmanship and finishing. It is manufactured from 100% Polypropylene construction
2. Our main business focuses on the development and production of high quality sintered metal filter , which creates our leadership in the field of sintered metal filter cartridge . It does not secrete dissoluble material during operation
3. By using advanced production technology, performance such as sintered metal filter cartridge has been realized on sintered metal filter . Its unique density gradient construction maximizes efficiency and minimizes pressure drop
4. This product undergoes in-house quality assurance procedures conducted by our QC team. It is resistant to putridity, acid and alkali, organic or inorganic solvent
5. Combining sintered metal filter cartridge with sintered metal filter elements makes sintered metal filter more applicable. The filter media is thermally bonded to prevent fiber release while providing consistent flow rates
sintered metal filter liquid Lvyuan 11
Sintered Titanium water filter cartridge is based on pure titanium powder (99.7% or higher) as the main raw material, made through high temperature sintering process. The uniform structure, small pore density is high, the filtration resistance, good permeability. Also it has the high filtration precision, acid & alkali corrosion, high temperature resistant characteristic. It can be used for solid liquid, gas separation and purification. The service performance is excellent, but the suction filter and press-filter, it will not form secondary pollution, simple operation, it can be on-line regeneration, easy to clean, and long service life.


  Product Feature

  • ◪    Uniform structure, narrow pore size distribution, and high separation efficiency;

  • ◪   High porosity, the resistance of filtration less, and the penetration efficiency is high;

  • ◪   High temperature resistant, it can be normally used below in 280 degree;

  • ◪   Good chemical stability, acid & alkali corrosion resistance, and oxidation resistance;

  • ◪   No particles fall off, it will not make the concentrate form secondary pollution, it conforms to be food hygiene and pharmaceutical GMP requirements;

  • ◪   Good mechanical performance, it can have the suction filtration and press-filtration, simple operation;

  • ◪   Low differential pressure, the area of cover is small, and large water flow rate;od mechanical performance, it can have the suction filtration and press-filtration, simple operation;

  • ◪   Strong antimicrobial ability, no microbes.

  • ◪   The finished-products technology is good, the overlength of overall length can be reached to 1000mm.

  • ◪   It can be on-line regeneration, easy to clean, and long service life.


Product Parameter



Fiter Cartridge dimensions
Length5’’ (125mm), 10’’ (250mm), 20’’ (500mm), 30’’ (750mm), 40’’ (1000mm
DiameterØ22, 30, 50, 60, 70, 80, 100, 120mm
Other dimensionsCustomized by customer’s request.
Material of constructions
Filter mediaTitanium
Connector typeFlat, Insert type, Thread type, Fin
End capsDOE, 215, 222, 226, M20, M30, M42 or as request.
Sealing materialSilicone, NBR, EPDM, Fluoro rubber, etc
Performance
Removal rate0.1, 0.45, 1, 3, 5, 10,20, 30, 40, 50, 100um
Porosity28-50%
Temperature Tolerance≦300℃ wet
Permeability0.02-20L/cm2 min Pa
Maximum Operating Pressure differential6.0bar
Flow rate (L/H)180, 200, 250, 280, 300, 350, 500, 800, 1000, 1500, 1600


◆◆Pure water flow rate reference table: the initial value of 10'' sintered titanium cartridge (P=0.2 MPa, 1cP, 25℃)

Micron rate (μm)0.20.451235102030
Flow rate (L/H)1802002502803003505008001000



Product Details



sintered metal filter liquid Lvyuan 12

part.1
Various end caps. End caps can be customized as request.
sintered metal filter liquid Lvyuan 13

part.2
Various dimensions. Dimension can be customized as request.
sintered metal filter liquid Lvyuan 14

part.3
Wall thickness can be tailor made as request, 1mm, 2mm, 3mm, etc.



Product Applications



sintered metal filter liquid Lvyuan 15
Pharmaceutical industry


sintered metal filter liquid Lvyuan 16
Chemical industry
sintered metal filter liquid Lvyuan 17
Electronic industry
sintered metal filter liquid Lvyuan 18
Water treatment industry
sintered metal filter liquid Lvyuan 19
Food and beverage industry
sintered metal filter liquid Lvyuan 20
Oil refining industry
