ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 1

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 2

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 3

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 4

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 5

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 6

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment

Inquiry

Write a Review

Overview

Quick Details

Applicable Industries:: Manufacturing Plant, Food & Beverage Factory, water treatment

Place of Origin:: Guangdong, China

Brand Name:: Lvyuan, OEM, ODM

Material:: staniless steel 304/ss304

Weight:: 21kg

Size:: 370*370*900mm

Power:: 0

Warranty:: 1 Year

After-sales Service Provided:: Online support

Certification:: ISO9001

Model:: BFL-1

material:: sus304

filter bag size:: 180*450mm

outer/inner:: polished

Working pressure:: 100Psi

closure:: V-clamp

sealing:: silicon/viton O-ring

inlet/outlet:: NPT threaded

Design temperature:: 100℃

Packaging & Delivery

Selling Units:: Single item

Single package size:: 35X35X90 cm

Single gross weight:: 18.000 kg

Package Type:: paper carton and bubble film

Lead Time :

Quantity(Pieces)	1 - 10	11 - 50	51 - 100	>100
Est. Time(days)	15	25	35	To be negotiated

Product Description

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 7

1. The bag filter has large flow rate capacity, small volume and dirt holding capacity.

2. It is convenient and quick to replace the filter bag, and the filter is no-clean, saving labor and time.

3. The side leakage rate of the filter bag is small, which greatly improves the filtration quality.

4. The bag filter can withstand greater working pressure, low pressure loss, low operating cost and obvious energy saving effect.

5. Filter bag filtration accuracy has been continuously improved and has reached 0.5um.

6. The bag filter has a wide range of applications, flexible use and various installation methods. Widely used in environmental protection, chemical, metallurgical, pharmaceutical, food and other industries.

Products Show

LY-BFL Stainless Steel BAG Filter Housing standard Specification:

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 9

Material	SS304
Bag material	PP/PE/SS
Finishing	outer-polished or sand blast surface inner-polished
Closure	V-clamp
Inlet/Outlet	2''NPT threaded
Pressure	Maximum 0.7 Mpa/100psi Continuous operating 0.5 Mpa/72.5psi
Sealing	EPDM O-ring
Filter bag	180*450mm

Users can choose filter bags of different shapes, different apertures, different structures and different materials according to different filtering needs to obtain the most economical and effective filtering effect.

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 11

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 13

Product list

ss304 Bag Filter Housing 100 Psi with 1 micron water single-bag filter Stainless Steel housing for water treatment 15

NO.	Name	Quantiy/ Material
1	1 Leg 500x38x38x3.0 mm	3pcs/ss304
2	Bottom head φ200x1.5 mm	1pcs/ss304
3	Housing body φ200x1.5 mm	1pcs/ss304
4	Basket φ170x380 mm	1pcs/ss304
5	Clamp-bolt for leg M10	2sets/ss304
6	Internal flange φ198x173x16	1pcs/ss304
7	Plate	1set/ss304
8	V-brand clamp φ200 mm	1set/ss304
9	Upper head φ200x1.5 mm	1pcs/ss304
10	Vent 1/4" thread	1pcs/ss304
11	EPDM O-ring	1pcs/ss304
12	Water inlet 2" NPT thread	1pcs/ss304
13	Water outlet 2" NPT thread	1pcs/ss304

1.How I choose the bag filter housing size?

We can recommand one for you.As you tell us what kind of fluid you want to filter, including flow rate, operating pressure, temperature, acid value etc.

2.How about the lead time?

Usually,within 10 working days.if you have request ,could you pl tell us your delivery day ,we will check the production schedule,and give you exact answer.If we can reduce the lead time,we will try our best.

3.Can we order small quantity?

Yes, we can accept samples purchase and we hope built long term relationship with you.
