Lvyuan Filter-Industrial Water Filter Cartridge & Housing Manufacturer Since 2009.
steel pleated micron stainless Lvyuan
Start Port:
Guangzhou
Place of Origin:
Guangdong, China
Payment:
T/T, Alibaba Trade Assurance, paypal
MOQ:
10pcs
Model:
LY-PL-PTFE
Delivery Time:
Within 7 working days
Certification:
SGS
Brand:
LVYUAN
Product Comparison
water filter manufacturer is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.Lvyuan Water Purification Equipment 's water filter cartridges are reasonably designed. They are stable in performance and easy in operation. They are quality-reliable and use-durable. water filter manufacturer is more competitive than other products in the same category, as shown in the following aspects.
-
v s
Application Scope
water filter manufacturer's application range is specifically as follows.Lvyuan Water Purification Equipment is committed to providing customers with high-quality water filter cartridges as well as one-stop, comprehensive and efficient solutions.Based on the advanced production technology, Lvyuan Water Purification Equipment produces highly automated and performance-stable water filter manufacturer according to customers' needs.
1. is an excellent on . It will trap larger particles in the outer layers and capture smaller particles in the deep layer
2. Lvyuan has gained more fame for its spectacular . It is manufactured from 100% Polypropylene construction
3. has many advantages, such as . The self-supporting fiber matrix enables a coreless design that is both economical and strong
4. Guangzhou Lvyuan Water Purification Equipment Co., Ltd. has increased its competitiveness in market through strenuous efforts. Being thermally welded, its caps are not prone to crack or fall off
5. Quality control of is the basis for Guangzhou Lvyuan Water Purification Equipment Co., Ltd.. Customized end cap configurations are available to fit specific requirements
PTFE membrane cartridge filter is constructed of imported natural
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. The adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
hydrophobic PTFE(Polytetrafluoroethylene) membrane and non-woven support materials. The adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution. These economical PTFE membrane cartridge filters provide superior hydrophobicity as compared to polypropylene filters commonly used in compressed air applications, making it ideally suited for utility as well as tank vent applications, without the higher costs of the typical PTFE filter.
Product Feature
◪ Excellent hydrophobic performance, the water erosion is more resistant than the common PVDF membrane.
◪ Withstand the water shocks, back pressures and repeated high temperature sterilizations.
◪ 100% bacterial retention & effective filtration to 0.02um particle.
◪ 100% integrity tested.
◪ It is constructed of 2 kinds of hot welding materials(PTFE & PP), no any adhesives, clean & stable, meet the high standards of pharmaceutical industry.
Product Parameter
| Product Name | 10 inch PTFE membrane pleated filter cartridge with stainless steel 222 |
| Filter media | PTFE membrane |
| Support | PP/Polypropylene |
| Core/End cap | PP/Polypropylene |
| Seal material | Silicone/EPDM/VITON/PTFE/NBR/TEFLON |
| Outer diameter | 2.7”(69mm) |
| Length | 9.75”, 10”, 20”, 30”, 40”, Customized |
| End cap | 215/222/226/FIN/DOE/SS |
| Filtration area | ≥0.72m² |
| Max.operating temperature | 80℃ |
| Micron rating(μm) | 0.2, 0.45 |
Product Details
part.1
It is constructed of 2 kinds of hot welding materials(PTFE & PP), no any adhesives,
clean & stable.
part.2
DOE double opened PTFE membrane filter with PTFE gasket.It is a good choice for the pharmaceutical and ohter strict applications.
part.3
The adapters are thermally welded without the uses of glues or adhesives to prevent any possibility of pollution.
part.4
Different length & variety end cap are optional.
Product Applications
Reverse osmosis water system prefiltration
Electronic l industry
Filtration of mineral water
Filtration of organic solvent & ink
Filtration of pharmaceuticals
Filtration of biological
Company Features
1. As one of largest manufacturer, Guangzhou Lvyuan Water Purification Equipment Co., Ltd. is regarded as the most reliable enterprise.
2. Quality assurance is the lifeline of Lvyuan which greatly guarantees the quality of .
3. We hope that our professional and services will win the market. Get more info!
